COMPONENT PARTS LIST
Critical safety components are identified by
the letter “X” in their component designators
and are shaded. Replace only with part
numbers specified.
CM151 4-22 CA - COMPONENTS
RC REF PART# DESCRIPTION
RC REF PART# DESCRIPTION
SEE REFERENCE CHART ON PAGE 4-12
ABCDEHJKLMNOTUVWa R2260M 063-11059-25A RESISTOR, THICK FILM CHIP,
100 OHM 5% 1/10W
ABCDEHJKLMNOTUVWa R2261M 063-11059-29A RESISTOR, THICK FILM CHIP,
150 OHM 5% 1/10W
ABCDEHJKLMNOTUVWa R2262M 063-11059-29A RESISTOR, THICK FILM CHIP,
150 OHM 5% 1/10W
ABCDEFGHIJKLMNOPQRSTUVWXYZa R2263 063-10236-32 RESISTOR, FILM, 330K OHM
5% 1/4W
ABCDEFGHIJKLMNOPQRSTUVWXYZa R2264 063-10236-44 RESISTOR, FILM, 1M OHM 5%
1/4W
ABCDEFGHIJKLMNOPQRSTUVWXYZa R2265M 063-11059-73A RESISTOR, THICK FILM CHIP,
10K OHM 5% 1/10W
R2265M 063-11059-73A RESISTOR/ THICK FILM CHIP/
10K OHM 5% 1/10W
HTUVWXY R2266 063-10235-64 RESISTOR, FILM, 470 OHM 5%
1/4W
HTUVWXY R2267M 063-11059-83A RESISTOR, THICK FILM CHIP,
27K OHM 5% 1/10W
HTUVWXY R2268M 063-11059-97A RESISTOR, THICK FILM CHIP,
100K OHM 5% 1/10W
ABCDEJKLMNOa R2269M 063-11059-09A RESISTOR, THICK FILM CHIP,
22 OHM 5% 1/10W
FGHIPQRSTUVWZ R2269M 063-11059-73A RESISTOR, THICK FILM CHIP,
10K OHM 5% 1/10W
HTUVWXY R2501M 063-11059-49A RESISTOR, THICK FILM CHIP,
1K OHM 5% 1/10W
HTUVWXY R2502M 063-11059-65A RESISTOR, THICK FILM CHIP,
4.7K OHM 5% 1/10W
HTUVWXY R2504M 063-11059-49A RESISTOR, THICK FILM CHIP,
1K OHM 5% 1/10W
HTUVWXY R2505M 063-11059-35A RESISTOR, THICK FILM CHIP,
270 OHM 5% 1/10W
HTUVWXY R2507M 063-11059-25A RESISTOR, THICK FILM CHIP,
100 OHM 5% 1/10W
HTUVWXY R2508M 063-11059-77A RESISTOR, THICK FILM CHIP,
15K OHM 5% 1/10W
HTUVWXY R2509M 063-11060-61A RESISTOR, THICK FILM CHIP,
4.7M OHM 5% 1/10W
HTUVWXY R2510M 063-11059-37A RESISTOR, THICK FILM CHIP,
330 OHM 5% 1/10W
HTUVWXY R2511M 063-11059-65A RESISTOR, THICK FILM CHIP,
4.7K OHM 5% 1/10W
HTUVWXY R2512M 063-11059-37A RESISTOR, THICK FILM CHIP,
330 OHM 5% 1/10W
HTUVWXY R2513M 063-11059-73A RESISTOR, THICK FILM CHIP,
10K OHM 5% 1/10W
HTUVWXY R2516M 063-11059-41A RESISTOR, THICK FILM CHIP,
470 OHM 5% 1/10W
HTUVWXY R2517M 063-11059-41A RESISTOR, THICK FILM CHIP,
470 OHM 5% 1/10W
HTUVWXY R2518M 063-11059-41A RESISTOR, THICK FILM CHIP,
470 OHM 5% 1/10W
HTUVWXY R2519M 063-11059-65A RESISTOR, THICK FILM CHIP,
4.7K OHM 5% 1/10W
HTUVWXY R2520 063-10235-72 RESISTOR, FILM, 1K OHM 5%
1/4W
HTUVWXY R2521M 063-11059-37A RESISTOR, THICK FILM CHIP,
330 OHM 5% 1/10W
HTUVWXY R2523M 063-11059-57A RESISTOR, THICK FILM CHIP,
2.2K OHM 5% 1/10W
HTUVWXY R2524M 063-11059-49A RESISTOR, THICK FILM CHIP,
1K OHM 5% 1/10W
HTUVWXY R2525M 063-11059-33A RESISTOR, THICK FILM CHIP,
220 OHM 5% 1/10W
HTUVWXY R2529 063-10235-64 RESISTOR, FILM, 470 OHM 5%
1/4W
HTUVWXY R2530M 063-11059-84A RESISTOR, THICK FILM CHIP,
30K OHM 5% 1/10W
HTUVWXY R2531M 063-11060-04A RESISTOR, THICK FILM CHIP,
200K OHM 5% 1/10W
HTUVWXY R2532M 063-11059-51A RESISTOR, THICK FILM CHIP,
1.2K OHM 5% 1/10W
HTUVWXY R2533M 063-11059-59A RESISTOR, THICK FILM CHIP,
2.7K OHM 5% 1/10W
HTUVWXY R2534 063-10235-48 RESISTOR, FILM, 100 OHM
5% 1/4W
HTUVWXY R2535 063-10235-48 RESISTOR, FILM, 100 OHM
5% 1/4W
HTUVWXY R2539M 063-11059-73A RESISTOR, THICK FILM CHIP,
10K OHM 5% 1/10W
HTUVWXY R2540M 063-11059-73A RESISTOR, THICK FILM CHIP,
10K OHM 5% 1/10W
HTUVWXY R2541M 063-11059-73A RESISTOR, THICK FILM CHIP,
10K OHM 5% 1/10W
HTUVWXY R2542M 063-11059-73A RESISTOR, THICK FILM CHIP,
10K OHM 5% 1/10W
HTUVWXY R2543M 063-11059-73A RESISTOR, THICK FILM CHIP,
10K OHM 5% 1/10W
HTUVWXY R2544M 063-11059-73A RESISTOR, THICK FILM CHIP,
10K OHM 5% 1/10W
HTUVWXY R2545 063-10235-96 RESISTOR, FILM, 10K OHM
5% 1/4W
HTUVWXY R2546M 063-11059-75A RESISTOR, THICK FILM CHIP,
12K OHM 5% 1/10W
HTUVWXY R2547M 063-11059A RESISTOR, THICK FILM CHIP,
0 OHM 5% 1/10W
HTUVWXY R2549 063-10565-12 RESISTOR, FILM, 3.3 OHM 5%
1/2W
FGHIPQRSTUVWXYZ R2901M 063-11059-71A RESISTOR, THICK FILM CHIP,
8.2K OHM 5% 1/10W
FGHIPQRSTUVWXYZ R2902M 063-11059-57A RESISTOR, THICK FILM CHIP,
2.2K OHM 5% 1/10W
FGIPQRSXYZ R2907 063-10235-72 RESISTOR, FILM, 1K OHM 5%
1/4W
FGIPQRSXYZ R2908 063-10235-40 RESISTOR, FILM, 47 OHM 5%
1/4W
FGIPQRSXYZ R2909 063-10235-83 RESISTOR, FILM, 3K OHM 5%
1/4W
FGIPQRSXYZ R2910M 063-11059-73A RESISTOR, THICK FILM CHIP,
10K OHM 5% 1/10W
FGIPQRSXYZ R2911 063-10235-45 RESISTOR, FILM, 75 OHM 5%
1/4W
FGIPQRSXYZ R2912 063-10235-45 RESISTOR, FILM, 75 OHM 5%
1/4W
DEFGHILMNOPQRSTUVWXYZ R2914 063-10235-40 RESISTOR, FILM, 47 OHM 5%
1/4W
HTUVWXY R2915M 063-11059-71A RESISTOR, THICK FILM CHIP,
8.2K OHM 5% 1/10W
DEFGHILMNOPQRSTUVWXYZ R2916 063-10235-45 RESISTOR, FILM, 75 OHM 5%
1/4W
HTUVW R2917M 063-11059-60A RESISTOR, THICK FILM CHIP,
3K OHM 5% 1/10W
XY R2917M 063-11059-61A RESISTOR, THICK FILM CHIP,
3.3K OHM 5% 1/10W
XY R2918M 063-11059-60A RESISTOR, THICK FILM CHIP,
3K OHM 5% 1/10W
XY R2919M 063-11059-41A RESISTOR, THICK FILM CHIP,
470 OHM 5% 1/10W
XY R2920M 063-11059-49A RESISTOR, THICK FILM CHIP,
1K OHM 5% 1/10W
XY R2921M 063-11059-49A RESISTOR, THICK FILM CHIP,
1K OHM 5% 1/10W
XY R2922M 063-11059-73A RESISTOR, THICK FILM CHIP,
10K OHM 5% 1/10W
XY R2923M 063-11059-51A RESISTOR, THICK FILM CHIP,
1.2K OHM 5% 1/10W
ABCDEFGHIJKLMNOPQRSTUVWXYZa R3201M 063-11059-65A RESISTOR, THICK FILM CHIP,
4.7K OHM 5% 1/10W
ABCDEFGHIJKLMNOPQRSTUVWXYZa R3202M 063-11059-29A RESISTOR, THICK FILM CHIP,
150 OHM 5% 1/10W
