Zenith B25A76R - Page 82

COMPONENT PARTS LIST
RC REF PART# DESCRIPTION
CM151 4-23 CA - COMPONENTS
RC REF PART# DESCRIPTION
Critical safety components are identified by
the letter “X” in their component designators
and are shaded. Replace only with part
numbers specified.
SEE REFERENCE CHART ON PAGE 4-128
ABCDEFGHIJKLMNOPQRSTUVWXYZa R3203 063-11087-64 RESISTOR, FILM, 470 OHM 5%
1/2W
ABCDEFGHIJKLMNOPQRSTUVWXYZa R3204 063-11087-66 RESISTOR, FILM, 560 OHM 5%
1/2W
ABCDEFGHIJKLMNOPQRSTUVWXYZa R3205 063-11087-66 RESISTOR, FILM, 560 OHM 5%
1/2W
ABCDEFGHIJKLMNOPQRSTUVWXYZa R3412M 063-11059-73A RESISTOR, THICK FILM CHIP,
10K OHM 5% 1/10W
ABCDEFGHIJKLMNOPQRSTUVWXYZa R3414 063-10235-80 RESISTOR, FILM, 2.2K OHM 5%
1/4W
ABCDEFGHIJKLMNOPQRSTUVWXYZa R3418 063-10235-88 RESISTOR, FILM, 4.7K OHM 5%
1/4W
ABCDEFGHIJKLMNOPQRSTUVWXYZa R3419 063-10235-88 RESISTOR, FILM, 4.7K OHM 5%
1/4W
ABCDEFGHIJKLMNOPQRSTUVWXYZa R3440 063-10243-48 RESISTOR, FILM, 100 OHM 5%
1/2W
ABCDEFGHIJKLMNOPQRSTUVWXYZa R5101M 063-11059-49A RESISTOR, THICK FILM CHIP,
1K OHM 5% 1/10W
ABCDEFGHIJKLMNOPQRSTUVWXYZa R5102M 063-11059-17A RESISTOR, THICK FILM CHIP,
47 OHM 5% 1/10W
ABCDEFGHIJKLMNOPQRSTUVWXYZa R5103 063-10244-22 RESISTOR, FILM, 120K OHM 5%
1/2W
ABCDEFGHIJKLMNOPQRSTUVWXYZa R5105M 063-11059-27A RESISTOR, THICK FILM CHIP,
120 OHM 5% 1/10W
ABCDEFGHIJKLMNOPQRSTUVWXYZa R5106M 063-11059-17A RESISTOR, THICK FILM CHIP,
47 OHM 5% 1/10W
ABCDEFGHIJKLMNOPQRSTUVWXYZa R5107 063-10243-72 RESISTOR, FILM, 1K OHM 5%
1/2W
ABCDEFGHIJKLMNOPQRSTUVWXYZa R5108M 063-11059-49A RESISTOR, THICK FILM CHIP,
1K OHM 5% 1/10W
ABCDEFGHIJKLMNOPQRSTUVWXYZa R5109M 063-11059-17A RESISTOR, THICK FILM CHIP,
47 OHM 5% 1/10W
ABCDEFGHIJKLMNOPQRSTUVWXYZa R5110 063-10244-22 RESISTOR, FILM, 120K OHM 5%
1/2W
ABCDEFGHIJKLMNOPQRSTUVWXYZa R5112M 063-11059-27A RESISTOR, THICK FILM CHIP,
120 OHM 5% 1/10W
ABCDEFGHIJKLMNOPQRSTUVWXYZa R5113M 063-11059-17A RESISTOR, THICK FILM CHIP,
47 OHM 5% 1/10W
ABCDEFGHIJKLMNOPQRSTUVWXYZa R5114 063-10235-64 RESISTOR, FILM, 470 OHM 5%
1/4W
ABCDEFGHIJKLMNOPQRSTUVWXYZa R5115 063-10243-72 RESISTOR, FILM, 1K OHM 5%
1/2W
ABCDEFGHIJKLMNOPQRSTUVWXYZa R5116 063-10243-72 RESISTOR, FILM, 1K OHM 5%
1/2W
ABCDEFGHIJKLMNOPQRSTUVWXYZa R5117M 063-11059-49A RESISTOR, THICK FILM CHIP,
1K OHM 5% 1/10W
ABCDEFGHIJKLMNOPQRSTUVWXYZa R5118M 063-11059-17A RESISTOR, THICK FILM CHIP,
47 OHM 5% 1/10W
ABCDEFGHIJKLMNOPQRSTUVWXYZa R5119 063-10244-22 RESISTOR, FILM, 120K OHM 5%
1/2W
ABCDEFGHIJKLMNOPQRSTUVWXYZa R5120M 063-11059-27A RESISTOR, THICK FILM CHIP,
120 OHM 5% 1/10W
ABCDEFGHIJKLMNOPQRSTUVWXYZa R5121M 063-11059-17A RESISTOR, THICK FILM CHIP,
47 OHM 5% 1/10W
ABCDEFGHIJKLMNOPQRSTUVWXYZa R5123 063-10243-72 RESISTOR, FILM, 1K OHM 5%
1/2W
ABCDEFGHIJKLMNOPQRSTUVWXYZa R5124M 063-11059-71A RESISTOR, THICK FILM CHIP,
8.2K OHM 5% 1/10W
ABCDEFGHIJKLMNOPQRSTUVWXYZa R5125 063-10235-72 RESISTOR, FILM, 1K OHM 5%
1/4W
ABCDEFGHIJKLMNOPQRSTUVWXYZa R5126 063-10244-28 RESISTOR, FILM, 220K OHM 5%
1/2W
ABCDEFGHIJKLMNOPQRSTUVWXYZa R5127 063-10243-72 RESISTOR, FILM, 1K OHM 5%
1/2W
ABCDEFGHIJKLMNOPQRSTUVWXYZa R6001M 063-11059-65A RESISTOR, THICK FILM CHIP,
4.7K OHM 5% 1/10W
ABCDEFGHIJKLMNOPQRSTUVWXYZa R6002M 063-11059-33A RESISTOR, THICK FILM CHIP,
220 OHM 5% 1/10W
ABCDEFGHIJKLMNOPQRSTUVWXYZa R6003M 063-11059-73A RESISTOR, THICK FILM CHIP,
10K OHM 5% 1/10W
ABCDEFGHIJKLMNOPQRSTUVWXYZa R6004M 063-11059-89A RESISTOR, THICK FILM CHIP,
47K OHM 5% 1/10W
ABCDEFGHIJKLMNOPQRSTUVWXYZa R6005M 063-11059-65A RESISTOR, THICK FILM CHIP,
4.7K OHM 5% 1/10W
ABCDEFGHIJKLMNOPQRSTUVWXYZa R6006M 063-11059-29A RESISTOR, THICK FILM CHIP,
150 OHM 5% 1/10W
ABCDEFGHIJKLMNOPQRSTUVWXYZa R6008M 063-11059-73A RESISTOR, THICK FILM CHIP,
10K OHM 5% 1/10W
ABCDEFGHIJKLMNOPQRSTUVWXYZa R6012 063-10236-12 RESISTOR, FILM, 47K OHM 5%
1/4W
ABCDEFGHIJKLMNOPQRSTUVWXYZa R6015 063-10235-72 RESISTOR, FILM, 1K OHM 5%
1/4W
ABCDEFGHIJKLMNOPQRSTUVWXYZa R6016 063-10235-72 RESISTOR, FILM, 1K OHM 5%
1/4W
ABCDEJKa R6017M 063-11059-73A RESISTOR, THICK FILM CHIP,
10K OHM 5% 1/10W
ABCDEJKa R6018 063-10235-96 RESISTOR, FILM, 10K OHM 5%
1/4W
ABCDEJKa R6019M 063-11059-49A RESISTOR, THICK FILM CHIP,
1K OHM 5% 1/10W
ABCDEJKa R6020M 063-11059-56A RESISTOR, THICK FILM CHIP,
2K OHM 5% 1/10W
a R6021 063-10235-72 RESISTOR/ FILM/ 1K OHM 5%
1/4W
ABCDEJK R6021M 063-11059-49A RESISTOR, THICK FILM CHIP,
1K OHM 5% 1/10W
ABCDEJKa R6022M 063-11059-49A RESISTOR, THICK FILM CHIP,
1K OHM 5% 1/10W
ABCDEJKa R6023M 063-11059-49A RESISTOR, THICK FILM CHIP,
1K OHM 5% 1/10W
ABCDEJKa R6024M 063-11059-56A RESISTOR, THICK FILM CHIP,
2K OHM 5% 1/10W
ABCDEJKa R6025M 063-11059-56A RESISTOR, THICK FILM CHIP,
2K OHM 5% 1/10W
ABCDEFGHIJKLMNOPQRSTUVWXYZa R6026 063-10235-96 RESISTOR, FILM, 10K OHM 5%
1/4W
ABCDEFGHIJKLMNOPQRSTUVWXYZa R6027 063-10235-80 RESISTOR, FILM, 2.2K OHM 5%
1/4W
ABCDEJKa R6028 063-10235-60 RESISTOR, FILM, 330 OHM 5%
1/4W
ABCDEJKa R6029M 063-11059-73A RESISTOR, THICK FILM CHIP,
10K OHM 5% 1/10W
ABCDEFGHIJKLMNOPQRSTUVWXYZa R6030 091-02053 WIRE, SOLID, BARE, 22 GA
COPPER
ABCDEFGHIJKLMNOPQRSTUVWXYZa R6031M 063-11059-49A RESISTOR, THICK FILM CHIP,
1K OHM 5% 1/10W
ABCDEFGHIJKLMNOPQRSTUVWXYZa R6032M 063-11059-77A RESISTOR, THICK FILM CHIP,
15K OHM 5% 1/10W
ABCDEFGHIJKLMNOPQRSTUVWXYZa R6033M 063-11059A RESISTOR, THICK FILM CHIP,
0 OHM 5% 1/10W
ABCDEFGHIJKLMNOPQRSTUVWXYZa R6034M 063-11060-21A RESISTOR, THICK FILM CHIP,
1 MEG OHM 5% 1/10W
ABCDEFGHIJKLMNOPQRSTUVWXYZa R6035M 063-11060-21A RESISTOR, THICK FILM CHIP,
1 MEG OHM 5% 1/10W
ABCDEFGHIJKLMNOPQRSTUVWXYZa R6036M 063-11059A RESISTOR, THICK FILM CHIP,
0 OHM 5% 1/10W
ABCDEFGHIJKLMNOPQRSTUVWXYZa R6037M 063-11059-83A RESISTOR, THICK FILM CHIP,
27K OHM 5% 1/10W
ABCDEFGHIJKLMNOPQRSTUVWXYZa R6039M 063-11059-33A RESISTOR, THICK FILM CHIP,
220 OHM 5% 1/10W
XY R6040M 063-11059-65A RESISTOR, THICK FILM CHIP,
4.7K OHM 5% 1/10W
ABCDEFGHIJKLMNOPQRSTUVWXYZa R6041 063-10235-56 RESISTOR, FILM, 220 OHM 5%
1/4W
ABCDEFGHIJKLMNOPQRSTUVWXYZa R6042M 063-11059-37A RESISTOR, THICK FILM CHIP,
330 OHM 5% 1/10W
ABCDEFGHIJKLMNOPQRSTUVWXYZa R6043 063-10235-56 RESISTOR, FILM, 220 OHM 5%
1/4W
ABCDEFGHIJKLMNOPQRSTUVWXYZa R6044M 063-11059-37A RESISTOR, THICK FILM CHIP,
330 OHM 5% 1/10W
