Zenith B27A74R - Factory Menu Recommended Settings

CM151 2-9 CA - INSTALLER MENUS
INSTALLERS MENU 221-1387 (continued)
CA CONSUMER CHASSIS
FACTORY MENU RECOMMENDED SETTINGS
ITEM RANGE 27” 32” 36” DESCRIPTION
00 F MODE 0-1 0 0 0 Factory mode - perfer to page 2-1
01 PRE PX 0-1 0 0 0 Used to store customer menu adjustments
02 V POS 0-30 15 15 15 Moves On Screen display vertically
03 H POS 0-45 9 9 9 Moves On Screen display horizontally
04 LEVEL 0-2 1 1 1
05 BAND 0-7 0 0 0 Broadcast Band adjustment
06 AC ON 0-1 0 0 0 AC power feature
TECHNICAL SETTINGS
07 RFB PF 0-1 1 1 1 Control for brightness in therefore mode
08 3.5T 0-1 1 1 1 3.58 MHz Trap
09 RF BRT 0-63 33 33 33 Control for brightness in RF mode
10 AX BRT 0-63 33 33 33 Control for brightness in AUX mode
11 V SIZE 0-254 170 120 175 Vertical Size
12 H SIZE 0-254 174 120 Horizontal size
13 V PHASE 0-7 0 2 1 Shifts picture vertically
14 H PHASE 0-31 13 14 14 Shifts picture horizontally
15 AUDLVL 0-63 46 46 46 Sound Attenuation
16 RF AGC 0-63 31 31 31 Weak channel adjustment
17 H AFC 0-1 1 1 1 Horizontal Automatic Frquency control
18 60 HZSW 0-2 2 2 2 60 Hertz Switched
19 PIFVCO 1-127 31 31 31 PIF Voltage Controlled Oscillator
COLOR TEMP STARTING VALUE
20 R CUT 0-254 0 0 0 B&W tracking adjustment
21 G CUT 0-254 0 0 0 B&W tracking adjustment
22 B CUT 0-254 0 0 0 B&W tracking adjustment
23 G GAIN 0-254 103 81 90 B&W tracking adjustment
24 B GAIN 0-254 75 75 90 B&W tracking adjustment
25 6 KEYS 0-1 1 0 0 Keyboard type
AUDIO SETTINGS
26 A ATT 0-15 9 9 9 Audio Attenuator
27 AVCO 0-63 31 31 31
28 AFILTER 0-63 31 31 31 Audio Filter
29 ASPECTRAL 0-63 31 31 31 Adjustment of Stereo seperation
30 WBAND 0-63 31 31 31 Wide band Low Frequency Seperation
PIP SETTINGS
32 PIP X1 POS 0-254 17 17 17 17 PIP Position X
1
33 PIP Y1 POS 0-254 25 25 25 25 PIP Position Y
1
34 PIP X2 POS 0-254 113 113 113 113 PIP Position X
2
35 PIP Y2 POS 0-254 143 143 143 143 PIP Position Y
2
36 PIP BRIGHTNESS 0-254 205 205 205 205 PIP Brightness
37 PIPR CONTRAST 0-127 50 50 50 50 PIP Red Contrast
38 PIPG CONTRAST 0-127 50 50 50 50 PIP Green Contrast
39 PIP ADJUST 0-15 2 2 2 2 PIP Adjust
40 PIPY DELAY 0-15 10 10 10 10 PIP Y Delay Luma
41 PIP BGSTART 0-31 10 10 10 10 PIP Burst Gate Start
42 PIP ACC LEVEL 0-63 20 20 20 20 PIP Color Gain
43 PIP HX 0-63 30 30 30 30 PIP Horizontal Phase
44 PIP VXS 0-63 40 41 41 41 PIP Vertical Phase
46 PIP COMP 0-3 2 2 2 2 PIP External Syncronic
DIFFERENCES FOR 221-1387-01
39 PIPY DELAY 0-15 10 10 10 10 PIP Y Delay Luma
40 PIP BGSTART 0-31 10 10 10 10 PIP Burst Gate Start
41 PIP ACC LEVEL 0-63 20 20 20 20 PIP Color Gain
42 PIP HX 0-63 30 30 30 30 PIP Horizontal Phase
43 PIP VXS 0-63 40 41 41 41 PIP Vertical Phase
44 PIP COMP 0-3 2 2 2 2 PIP External Syncronic
45 XTAL 0-1 0 0 0 0 External crystal
Note: If you change the EPROM, change the microprocessor from 221-1387-00 to 221-1387-01
