CM151 4-1 CA - MODEL PARTS
MODEL PARTS
SECTION 4
MODEL PARTS
B25A02Z
Part # Description
014-12296-17 CABINET FRONT, TV, MOLDED PLASTIC
014-12297-08 CABINET REAR, TV, MOLDED PLASTIC
020-04330-42 COIL, DEGAUSSER
024-03372 COVER, BLANK, 2 X 5 SPEAKER OPENING
030-01532 DECORATIVE ITEM, LOGO, ZENITH
046-10578 KNOB ARRAY, PUSH BUTTON, 6 POSITION
049-01368-03 SPEAKER, OVAL, 6 X 13 CM
050-02576-08 CONNECTOR AND CABLE ASSEMBLY
095-04456-06 TRANSFORMER, DEFLECTION, YOKE, 25V HIBI
COMERCIAL
A63AFW38X VACUUM TUBE, CRT, COLOR, 25 INCH DIAGONAL
124-00213-23 SPACE COMMAND TRANSMITTER, TV ONLY SC3492Z
152-00335 WEDGE, YOKE SPACER/POSITIONER
192-00916 LENS, IR
206-03551 INSTR BOOK, OPERATION GUIDE
A-07690-06 MAGNET ASSEMBLY, STATIC CONVERGENCE AND
PURITY
A-18681-01 LINE CORD ASSY WITH YEONHO CONNECTOR
A-18695-02 GND STRAP ASSY, CRT
B25A10Z, B25A10ZC, B25A10Z6, B25A10ZC6
Part # Description
014-12296-17 CABINET FRONT, TV, MOLDED PLASTIC
014-12297-08 CABINET REAR, TV, MOLDED PLASTIC
020-04330-42 COIL, DEGAUSSER
030-01532 DECORATIVE ITEM, LOGO, ZENITH
046-10578 KNOB ARRAY, PUSH BUTTON, 6 POSITION
049-01368-03 SPEAKER, OVAL, 6 X 13 CM
095-04456-06 TRANSFORMER, DEFLECTION YOKE, 25V HIBI
COMERCIAL
A63AFW38X VACUUM TUBE, CRT, COLOR, 25 INCH DIAGONAL
124-00213-23 SPACE COMMAND, TRANSMITTER, TV ONLY
SC3492Z
152-00335 WEDGE, YOKE SPACER/POSITIONER
192-00916 LENS, IR
206-03476 INSTR BOOK, OPERATION GUIDE
A-07690-06 MAGNET ASSEMBLY, STATIC CONVERGENCE AND
PURITY
A-18681-01 LINE CORD ASSY WITH YEONHO CONNECTOR
A-18695-02 GND STRAP ASSY, CRT
B25A10ZCF
Part # Description
014-12296-17 CABINET FRONT, TV, MOLDED PLASTIC
014-12297-08 CABINET REAR, TV, MOLDED PLASTIC
020-04330-42 COIL, DEGAUSSER
030-01532 DECORATIVE ITEM, LOGO, ZENITH
046-10578 KNOB ARRAY, PUSH BUTTON, 6 POSITION
049-01368-03 SPEAKER, OVAL, 6 X 13 CM
095-04456-06 TRANSFORMER, DEFLECTION YOKE, 25V HIBI
COMERCIAL
A63AFW38X VACUUM TUBE, CRT, COLOR, 25 INCH DIAGONAL
124-00213-23 SPACE COMMAND, TRANSMITTER, TV ONLY
SC3492Z
152-00335 WEDGE, YOKE SPACER/POSITIONER
192-00916 LENS, IR
206-03476 INSTR BOOK, OPERATION GUIDE
206-03557 INSTR BOOK, OPERATION GUIDE
A-07690-06 MAGNET ASSEMBLY, STATIC CONVERGENCE AND
PURITY
A-18681-01 LINE CORD ASSY, WITH YEONHO CONNECTOR
A-18695-02 GND STRAP ASSY, CRT
B25A11Z, B25A11Z6
Part # Description
014-12296-17 CABINET FRONT, TV, MOLDED PLASTIC
014-12297-09 CABINET REAR, TV, MOLDED PLASTIC
020-04330-42 COIL, DEGAUSSER
030-01532 DECORATIVE ITEM, LOGO, ZENITH
046-10578 KNOB ARRAY, PUSH BUTTON, 6 POSITION
049-01368-03 SPEAKER, OVAL, 6 X 13 CM
095-04456-06 TRANSFORMER, DEFLECTION YOKE, 25V HIBI
COMERCIAL
A63AFW38X VACUUM TUBE, CRT, COLOR, 25 INCH DIAGONAL
124-00233 SPACE COMMAND, TRANSMITTER, MBR3447Z
152-00335 WEDGE, YOKE SPACER/POSITIONER
192-00916 LENS, IR
206-03477 INSTR BOOK, OPERATION GUIDE
A-07690-06 MAGNET ASSEMBLY, STATIC CONVERGENCE AND
PURITY
A-18681-01 LINE CORD ASSY, WITH YEONHO CONNECTOR
A-18695-02 GND STRAP ASSY, CRT
B25A11ZF
Part # Description
014-12296-17 CABINET FRONT, TV, MOLDED PLASTIC
014-12297-09 CABINET REAR, TV, MOLDED PLASTIC
020-04330-42 COIL, DEGAUSSER
030-01532 DECORATIVE ITEM, LOGO, ZENITH
046-10578 KNOB ARRAY, PUSH BUTTON, 6 POSITION
049-01368-03 SPEAKER, OVAL, 6 X 13 CM
095-04456-06 TRANSFORMER, DEFLECTION YOKE, 25V HIBI
COMERCIAL
A63AFW38X VACUUM TUBE, CRT, COLOR, 25 INCH DIAGONAL
124-00233 SPACE COMMAND, TRANSMITTER, MBR3447Z
152-00335 WEDGE, YOKE SPACER/POSITIONER
192-00916 LENS, IR
206-03477 INSTR BOOK, OPERATION GUIDE
206-03556 INSTR BOOK, OPERATION GUIDE
A-07690-06 MAGNET ASSEMBLY, STATIC CONVERGENCE AND
PURITY
A-18681-01 LINE CORD ASSY, WITH YEONHO CONNECTOR
A-18695-02 GND STRAP ASSY, CRT
B25A24Z, B25A24Z6
Part # Description
012-10858-04 MOLDED PLASTIC, PANEL, JACK PACK, CA CHASSIS
014-12143-02 CABINET TRAY, MOLDED PLASTIC
014-12181-09 CABINET REAR, TV, MOLDED PLASTIC
014-12187-14 CABINET FRONT, TV, MOLDED PLASTIC
020-04330-42 COIL, DEGAUSSER
030-01532 DECORATIVE ITEM, LOGO, ZENITH
046-10554 KNOB ARRAY, PUSH-BUTTON, 10 POSITIONS
049-01368-03 SPEAKER, OVAL, 6 X 13 CM
095-04456-06 TRANSFORMER, DEFLECTION YOKE, 25V HIBI
COMERCIAL
