Zenith B27A74R - Component Parts List

COMPONENT PARTS LIST
RC REF PART# DESCRIPTION
CM151 4-13 CA - COMPONENTS
RC REF PART# DESCRIPTION
Critical safety components are identified by
the letter “X” in their component designators
and are shaded. Replace only with part
numbers specified.
SEE REFERENCE CHART ON PAGE 4-128
ABCDEFGHIJKLMNOPQRSTUVWXYZa 2C5 050-01666-13 CONNECTOR&CABLE, ASSY,
2.5MM, 5 CONTACT, 2 UP
ABCDEFGHIJKLMNOPQRSTUVWXYZa 2F5 050-01665-12 CONNECTOR&CABLE, ASSY,
2.5MM, 4 CONTACT, 2 UP
FGHILMNOPQRSTUVWXYZ 2K6 058-00526-05 PLUG, 0.098P 5 CONTACT
ABCDEFGHIJKLMNOPQRSTUVWXYZa 3R8 058-00546-03 PLUG, MULTIPRONG, 3
POSITION
ABCDEFGHIJKLMNOPQRSTUVWXYZa 3T8 058-00546-02 PLUG, MULTIPRONG, 2
POSITION
ABCDEFGHIJKLMNOPQRSTUVWXYZa 3Y3 058-00546-04 PLUG, MULTIPRONG, 4
POSITION
ABCDEFGHIJKLMNOPQRSTUVWXYZa 4G9 058-00526-05 PLUG, 0.098P 5 CONTACT
ABCDEFGHIJKLMNOPQRSTUVWXYZa 9S4 058-00526-04 PLUG, 0.098P 4 CONTACT
ABCDEFGHIJKLMNOPQRSTUVWXYZa C0841 022-08310-16 CAP, 1000 MFD 20% 25V,
ELECTRO
ABCDEFGHIJKLMNOPQRSTUVWXYZa C0842 022-08049-24A CAP, 0.10 MFD 10% 50V,
POLYESTER
ABCDEFGHIJKLMNOPQRSTUVWXYZa C0843 022-08310-12A CAP, 100 MFD 20% 25V,
ELECTRO
BCDEFGHIJKLMNOPQRSTUVWXYZa C0851 022-08312-08A CAP, 10 MFD 20% 50V,
ELECTRO
ABCDEFGHIJKLMNOPQRSTUVWXYZa C0852 022-08309-12A CAP, 100 MFD 20% 16V,
ELECTRO
ABCDEFGHIJKLMNOPQRSTUVWXYZa C0853 022-08049-24A CAP, 0.10 MFD 10% 50V,
POLYESTER
BCDEFGHIJKLMNOPQRSTUVWXYZa C0854 022-08310-16 CAP, 1000 MFD 20% 25V,
ELECTRO
BCDEHJKLMNOTUVWa C0855M 022-08366-16A CAP, 4,700 PFD 10% 50V,
CERAMIC CHIP, LDLESS
A C0855M 022-08366-17A CAP, 5,600 PFD 10% 50V,
CERAMIC CHIP, LDLESS
FGIPQRSXYZ C0855M 022-08366-18A CAP, 6,800 PFD 10% 50V,
CERAMIC CHIP, LDLESS
ABCDEFGHIJKLMNOPQRSTUVWXYZa C0861 022-08312-08A CAP, 10 MFD 20% 50V,
ELECTRO
ABCDEFGHIJKLMNOPQRSTUVWXYZa C0862 022-08309-12A CAP, 100 MFD 20% 16V,
ELECTRO
ABCDEFGHIJKLMNOPQRSTUVWXYZa C0863 022-08049-24A CAP, 0.10 MFD 10% 50V,
POLYESTER
ABCDEFGHIJKLMNOPQRSTUVWXYZa C0864 022-08310-16 CAP, 1000 MFD 20% 25V,
ELECTRO
BCDEHJKLMNOTUVWa C0865M 022-08366-16A CAP, 4,700 PFD 10% 50V,
CERAMIC CHIP, LDLESS
A C0865M 022-08366-17A CAP, 5,600 PFD 10% 50V,
CERAMIC CHIP, LDLESS
FGIPQRSXYV C0865M 022-08366-18A CAP, 6,800 PFD 10% 50V,
CERAMIC CHIP, LDLESS
ABCDEFGHIJKLMNOPQRSTUVWXYZa C1200M 022-08368-20A CAP, 10,000 PFD 10% 25V,
CERAMIC CHIP, LDLESS
ABCDEFGHIJKLMNOPQRSTUVWXYZa C1201M 022-08366-08A CAP, 1,000 PFD 10% 50V,
CERAMIC CHIP, LDLESS
ABCDEFGHIJKLMNOPQRSTUVWXYZa C1202M 022-08368-20A CAP, 10,000 PFD 10% 25V,
CERAMIC CHIP, LDLESS
ABCDEFGHIJKLMNOPQRSTUVWXYZa C1203M 022-08366-08A CAP, 1,000 PFD 10% 50V,
CERAMIC CHIP, LDLESS
ABCDEFGHIJKLMNOPQRSTUVWXYZa C1204M 022-08366-08A CAP, 1,000 PFD 10% 50V,
CERAMIC CHIP, LDLESS
ABCDEFGHIJKLMNOPQRSTUVWXYZa C1205M 022-08368-20A CAP, 10,000 PFD 10% 25V,
CERAMIC CHIP, LDLESS
ABCDEFGHIJKLMNOPQRSTUVWXYZa C1206 022-08312-03A CAP, 0.47 MFD 20% 50V,
ELECTRO
ABCDEFGHIJKLMNOPQRSTUVWXYZa C1207 022-08312-03A CAP, 0.47 MFD 20% 50V,
ELECTRO
ABCDEFGHIJKLMNOPQRSTUVWXYZa C1208M 022-08370-24A CAP, 22,000 PFD 10% 16V,
CERAMIC CHIP, LDLESS
ABCDEFGHIJKLMNOPQRSTUVWXYZa C1209M 022-08368-20A CAP, 10,000 PFD 10% 25V,
CERAMIC CHIP, LDLESS
ABCDEFGHIJKLMNOPQRSTUVWXYZa C1210 022-08309-13A CAP, 220 MFD 20% 16V,
ELECTRO
ABCDEFGHIJKLMNOPQRSTUVWXYZa C1211M 022-08366-08A CAP, 1,000 PFD 10% 50V,
CERAMIC CHIP, LDLESS
ABCDEFGHIJKLMNOPQRSTUVWXYZa C1212 022-08312-03A CAP, 0.47 MFD 20% 50V,
ELECTRO
BCDEFGHIJKLMNOPQRSTUVWXYZa C1213M 022-08352-22A CAP, 27 PFD 5% 50V, CERAMIC
CHIP, LDLESS
A C1213M 022-08366-16A CAP, 4,700 PFD 10% 50V,
CERAMIC CHIP, LDLESS
ABCDEFGHIJKLMNOPQRSTUVWXYZa C1214 022-08312-07A CAP, 4.7 MFD 20% 50V,
ELECTRO
ABCDEFGHIJKLMNOPQRSTUVWXYZa C1215M 022-08368-20A CAP, 10,000 PFD 10% 25V,
CERAMIC CHIP, LDLESS
ABCDEFGHIJKLMNOPQRSTUVWXYZa C1216 022-08309-12A CAP, 100 MFD 20% 16V,
ELECTRO
ABCDEFGHIJKLMNOPQRSTUVWXYZa C1217M 022-08352-28A CAP, 47 PFD 5% 50V, CERAMIC
CHIP, LDLESS
ABCDEFGHIJKLMNOPQRSTUVWXYZa C1218M 022-08352-38A CAP, 120 PFD 5% 50V,
CERAMIC CHIP, LDLESS
ABCDEFGHIJKLMNOPQRSTUVWXYZa C1219M 022-08368-20A CAP, 10,000 PFD 10% 25V,
CERAMIC CHIP, LDLESS
ABCDEFGHIJKLMNOPQRSTUVWXYZa C1220M 022-08368-20A CAP, 10,000 PFD 10% 25V,
CERAMIC CHIP, LDLESS
ABCDEFGHIJKLMNOPQRSTUVWXYZa C1221M 022-08368-20A CAP, 10,000 PFD 10% 25V,
CERAMIC CHIP, LDLESS
ABCDEFGHIJKLMNOPQRSTUVWXYZa C1222 022-08309-13A CAP, 220 MFD 20% 16V,
ELECTRO
ABCDEFGHIJKLMNOPQRSTUVWXYZa C1223M 022-08366-08A CAP, 1,000 PFD 10% 50V,
CERAMIC CHIP, LDLESS
ABCDEFGHIJKLMNOPQRSTUVWXYZa C1224 022-08049-24A CAP, 0.10 MFD 10% 50V,
POLYESTER
FGIPQRSXYZ C1401M 022-08370-22A CAP, 15,000 PFD 10% 16V,
CERAMIC CHIP, LDLESS
FGIPQRSXYZ C1402M 022-08366-18A CAP, 6,800 PFD 10% 50V,
CERAMIC CHIP, LDLESS
FGIPQRSXYZ C1403M 022-08370-22A CAP, 15,000 PFD 10% 16V,
CERAMIC CHIP, LDLESS
FGIPQRSXYZ C1404M 022-08366-18A CAP, 6,800 PFD 10% 50V,
CERAMIC CHIP, LDLESS
FGIPQRSXYZ C1406M 022-08370-24A CAP, 22,000 PFD 10% 16V,
CERAMIC CHIP, LDLESS
DEFGHILMNOPQRSTUVWXYZ C1409 022-08312-07A CAP, 4.7 MFD 20% 50V,
ELECTRO
DEFGHILMNOPQRSTUVWXYZ C1410 022-08312-07A CAP, 4.7 MFD 20% 50V,
ELECTRO
BCDEFGHIJKLMNOPQRSTUVWXYZa C1413 022-08312-08A CAP, 10 MFD 20% 50V,
ELECTRO
BCDEFGHIJKLMNOPQRSTUVWXYZa C1414 022-07669-15A CAP, 10 MFD 10% 50V,
ELECTRO
BCDEFGHIJKLMNOPQRSTUVWXYZa C1415 022-08312-04A CAP, 1 MFD 20% 50V,
ELECTRO
BCDEFGHIJKLMNOPQRSTUVWXYZa C1416 022-08188-05A CAP, 10 MFD 20% 25V,
NONPLZD ELECTROLYTIC
BCDEFGHIJKLMNOPQRSTUVWXYZa C1417 022-08188-05A CAP, 10 MFD 20% 25V,
NONPLZD ELECTROLYTIC
BCDEFGHIJKLMNOPQRSTUVWXYZa C1418 022-08312-04A CAP, 1 MFD 20% 50V,
ELECTRO
BCDEFGHIJKLMNOPQRSTUVWXYZa C1419 022-07669-14A CAP, 3.3 MFD 10% 50V,
ELECTRO
BCDEFGHIJKLMNOPQRSTUVWXYZa C1420 022-08049-13A CAP, 0.012 MFD 10% 50V,
POLYESTER
BCDEFGHIJKLMNOPQRSTUVWXYZa C1421 022-08257-21A CAP, 5600 PFD 10% 50V,
CERAMIC DISC
BCDEFGHIJKLMNOPQRSTUVWXYZa C1422 022-08049-20A CAP, 0.047 MFD 10% 50V,
POLYESTER
BCDEHJKLMNOTUVWa C1423 022-08312-04A CAP, 1 MFD 20% 50V,
ELECTRO
BCDEFGHIJKLMNOPQRSTUVWXYZa C1424 022-08257-17A CAP, 2700 PFD 10% 50V,
CERAMIC DISC
FGIPQRSXYZ C1425 022-08312-07A CAP, 4.7 MFD 20% 50V,
ELECTRO
