Zenith B27A74R - Page 83

COMPONENT PARTS LIST
Critical safety components are identified by
the letter “X” in their component designators
and are shaded. Replace only with part
numbers specified.
CM151 4-24 CA - COMPONENTS
RC REF PART# DESCRIPTION
RC REF PART# DESCRIPTION
SEE REFERENCE CHART ON PAGE 4-12
BCDEJKLMNOa R6045M 063-11059-57A RESISTOR, THICK FILM CHIP,
2.2K OHM 5% 1/10W
A R6045M 063-11059-61A RESISTOR, THICK FILM CHIP,
3.3K OHM 5% 1/10W
FGHIPQRSTUVWXYZ R6045M 063-11059-65A RESISTOR, THICK FILM CHIP,
4.7K OHM 5% 1/10W
BCDEJKLMNOa R6046M 063-11059-56A RESISTOR, THICK FILM CHIP,
2K OHM 5% 1/10W
A R6046M 063-11059-61A RESISTOR, THICK FILM CHIP,
3.3K OHM 5% 1/10W
FGHIPQRSTUVWXYZ R6046M 063-11059-65A RESISTOR, THICK FILM CHIP,
4.7K OHM 5% 1/10W
ABCDEFGHIJKLMNOPQRSTUVWXYZa R6047M 063-11059-65A RESISTOR, THICK FILM CHIP,
4.7K OHM 5% 1/10W
ABCDEFGHIJKLMNOPQRSTUVWXYZa R6048M 063-11059-65A RESISTOR, THICK FILM CHIP,
4.7K OHM 5% 1/10W
ABCDEFGHIJKLMNOPQRSTUVWXYZa R6049 063-10235-56 RESISTOR, FILM, 220 OHM 5%
1/4W
ABCDEFGHIJKLMNOPQRSTUVWXYZa R6050M 063-11059-33A RESISTOR, THICK FILM CHIP,
220 OHM 5% 1/10W
ABCDEFGHIJKLMNOPQRSTUVWXYZa R6053M 063-11059-53A RESISTOR, THICK FILM CHIP,
1.5K OHM 5% 1/10W
ABCDEFGHIJKLMNOPQRSTUVWXYZa R6058M 063-11059-87A RESISTOR, THICK FILM CHIP,
39K OHM 5% 1/10W
ABCDEFGHIJKLMNOPQRSTUVWXYZa R6059M 063-11059-65A RESISTOR, THICK FILM CHIP,
4.7K OHM 5% 1/10W
ABCDEFGHIJKLMNOPQRSTUVWXYZa R6060M 063-11059-65A RESISTOR, THICK FILM CHIP,
4.7K OHM 5% 1/10W
ABCDEFGHIJKLMNOPQRSTUVWXYZa R6061M 063-11059-57A RESISTOR, THICK FILM CHIP,
2.2K OHM 5% 1/10W
FGHILMNOPQRSTUVWXYZ R6069M 063-11060-13A RESISTOR, THICK FILM CHIP,
470K OHM 5% 1/10W
FGHILMNOPQRSTUVWXYZ R6070M 063-11060-13A RESISTOR, THICK FILM CHIP,
470K OHM 5% 1/10W
ABCDEFGHIJKLMNOPQRSTUVWXYZa R6072 063-10235-96 RESISTOR, FILM, 10K OHM 5%
1/4W
ABCDEFGHIJKLMNOPQRSTUVWXYZa R6080 063-10236-41 RESISTOR, FILM, 750K OHM 5%
1/4W
HTUVWXY R6082M 063-11059-25A RESISTOR, THICK FILM CHIP,
100 OHM 5% 1/10W
ABCDEFGIJKLMNOPQRSZa R6082M 063-11059-41A RESISTOR, THICK FILM CHIP,
470 OHM 5% 1/10W
XY R6083M 063-11059-60A RESISTOR, THICK FILM CHIP,
3K OHM 5% 1/10W
XY R6084M 063-11059-73A RESISTOR, THICK FILM CHIP,
10K OHM 5% 1/10W
ABCDEFGHIJKLMNOPQRSTUVWXYZa R6090M 063-11059-49A RESISTOR, THICK FILM CHIP,
1K OHM 5% 1/10W
ABCDEFGHI RX2115 063-11110-04 RESISTOR, FILM, 1.5 OHM 5%
1/2W
JKLMNOPQRSTUVWXYZa RX2115 063-11110-06 RESISTOR, FILM, 1.8 OHM 5%
1/2W
ABCDEFGHI RX2116 063-11110-04 RESISTOR, FILM, 1.5 OHM 5%
1/2W
JKLMNOPQRSTUVWXYZa RX2116 063-11110-06 RESISTOR, FILM, 1.8 OHM 5%
1/2W
ABCDEFGHIJKLMNOPQRSTUVWXYZa RX2117 063-10235-10 RESISTOR, FILM, 2.7 OHM 5%
1/4W
ABCDEFGHIJKLMNOPQRSTUVWXYZa RX2124 063-11214-16 RESISTOR, FILM, 0.51 OHM 5%
1/2W
HTUVWXY RX2503 091-02053 WIRE, SOLID, BARE, 22 GA
COPPER
ABCDEFGHIJKLMNOPQRSTUVWXYZa RX3008 063-10936-37 RESISTOR, FILM, 2.21K OHM
1% 1/4W
ABCDEFGHIJKLMNOPQRSTUVWXYZa RX3009M 063-11059-97A RESISTOR, THICK FILM CHIP,
100K OHM 5% 1/10W
ABCDEFGHIJKLMNOPQRSTUVWXYZa RX3010M 063-11059-25A RESISTOR, THICK FILM CHIP,
100 OHM 5% 1/10W
ABCDEFGHIJKLMNOPQRSTUVWXYZa RX3016 063-10936-72 RESISTOR, FILM, 4.32K OHM
1% 1/4W
ABCDEFGHIJKLMNOPQRSTUVWXYZa RX3022 063-10936-72 RESISTOR, FILM, 4.32K OHM
1% 1/4W
ABCDEFGHIJKLMNOPQRSTUVWXYZa RX3207 063-10243-45 RESISTOR, FILM, 75 OHM 5%
1/2W
ABCDEFGHIJKLMNOPQRSTUVWXYZa RX3208 063-10565-10 RESISTOR, FILM, 2.7 OHM 5%
1/2W
ABCDEFGHIJKLMNOPQRSTUVWXYZa RX3209 063-10460-44A RESISTOR, WIREWOUND, 6.8
OHM 10% 10W
ABCDEFGHIJKLMNOPQRSTUVWXYZa RX3211 063-10565 RESISTOR, FILM, 1 OHM 5%
12W
ABCDEFGHIXY RX3212 063-10235-88 RESISTOR, FILM, 4.7K OHM
5% 14W
ABCDEFGHIJKLMNOPQRSTUVWXYZa RX3214 063-10244-04 RESISTOR, FILM, 22K OHM 5%
12W
ABCDEFGHIJKLMNOPQRSTUVWXYZa RX3215 063-10832-69B RESISTOR, FILM, 750 OHM 5%
1W
ABCDEFGHIJKLMNOPQRSTUVWXYZa RX3216 063-11160-60B RESISTOR, FILM, 330 OHM 5%
2W
JKLNPRTVZ RX3217 063-10442-28A RESISTOR, WIREWOUND, 1.5
OHM 5% 5W
ABCDEFGHI RX3217 063-10442-37A RESISTOR, WIREWOUND, 3.6
OHM 5% 5W
MOQSUWa RX3217 063-11164-02B RESISTOR, FILM, 1.2 OHM 5%
3W
XY RX3217 063-11164-10B RESISTOR, FILM, 2.7 OHM 5%
3W
ABCDEFGHIJKLMNOPQRSTUVWXYZa RX3218 063-10243-48 RESISTOR, FILM, 100 OHM 5%
1/2W
ABCDEFGHIJKLMNOPQRSTUVWXYZa RX3400 063-11264-01 RESISTOR, CARBON
COMPOSITION, 5.6M OHM 20%
1/2W
ABCDEFGHIJKLMNOPQRSTUVWXYZa RX3401 063-10444-20A RESISTOR, WIREWOUND, 0.68
OHM 10% 5W
ABCDEFGHIJKLMNOPQRSTUVWXYZa RX3403 063-10442-04A RESISTOR, WIREWOUND, 0.15
OHM 5% 5 WATT
ABCDEFGHIJKLMNOPQRSTUVWXYZa RX3404 063-11088-26 RESISTOR, FILM, 180K OHM
5% 1/2W
ABCDEFGHIJKLMNOPQRSTUVWXYZa RX3405 063-11164-02B RESISTOR, FILM, 1.2 OHM 5%
3W
ABCDEFGHIJKLMNOPQRSTUVWXYZa RX3406 063-10235-40 RESISTOR, FILM, 47 OHM 5%
1/4W
IZ RX3407 063-11156-40B RESISTOR, FILM, 47 OHM 5%
1W
ABCDEFGHJKLMNOPQRSTUVWXYa RX3407 063-11160-35B RESISTOR, FILM, 30 OHM 5%
2W
IZ RX3408 063-11156-32B RESISTOR, FILM, 22 OHM 5%
1W
ABCDEFGHJKLMNOPQRSTUVWXYa RX3408 063-11160-24B RESISTOR, FILM, 10 OHM 5%
2W
ABCDEFGHIJKLMNOPQRSTUVWXYZa RX3409 063-10565-28 RESISTOR, FILM, 15 OHM 5%
1/2W
ABCDEFGHIJKLMNOPQRSTUVWXYZa RX3417 063-10444-52B RESISTOR, WIREWOUND, 15
OHM 10% 5 WATT
K RX3423 063-11160-48B RESISTOR, FILM, 100 OHM 5%
2W
ABCDEFGHIJKLMNOPQRSZa RX3423 063-11160-52B RESISTOR, FILM, 150 OHM 5%
2W
HTUVWXY RX3427 063-10442-60B RESISTOR, WIREWOUND, 33
OHM 5% 5W
K RX3427 063-11160-48B RESISTOR, FILM, 100 OHM 5%
2W
ABCDEFGHIJKLMNOPQRSZa RX3427 063-11160-52B RESISTOR, FILM, 150 OHM 5%
2W
ABCDEHJKLMNOTUVWa RX3428 063-10235-54 RESISTOR, FILM, 180 OHM 5%
1/4W
FGIPQRSXYZ RX3428 063-10243-45 RESISTOR, FILM, 75 OHM 5%
1/2W
ABCDEFGHIJKLMNOPQRSTUVWXYZa RX5104 063-10837B RESISTOR, FILM, 15K OHM 5%
2W
