2. Symbols on the machine
For safe operation and maintenance, symbols are
carved in relief on the machine. According to these
indications, please be careful not to take a mistake.
(a) The port to refuel the "MIX GASOLINE"
Position:FUELTANKCAP
(b) The direction to close the choke
Position:AIRCLEANERCOVER
(c) The direction to open the choke
Position:AIRCLEANERCOVER
MODELCODE Unit BC3450DW BC4350DW
Overall size
Length mm 1835 1835
Width mm 620 620
Height mm 505 505
Dry weight Kg 7.31 7.55
Engine model ✽ G35L-D G45L-D
Displacement cc 33.6 41.5
Carburetor ✽ → Diaphragm
Fuel (Mixture ratio) ✽ → 50:1 (Gasoline and 2cycle oil)
Fuel tank capacity litter 0.74 0.94
Service range rpm → 5000~8000
Spark plug ✽ → NGK BPMR7A
Clutch system ✽ → Two-shoe Centrifugal-Type
Anti-vibration system
Housing ✽ Yes Yes
Handle-bracket ✽ No No
Gearhead
Neck angle deg → 60
Reduction ratio ✽ → 1.400
Blade rotation ✽ → Counter-clockwise
Handle type ✽ → Double
Throttle lever ✽ → Trigger Type (With Safety-lock)
Standard cutter ✽ → Nylon string head
3 Teeth blade
Harness type ✽ → Double
Quick release ✽ → Yes
Standard accessories
Goggle ✽ → ●
Tool-kit ✽ → ●
Owner's manual ✽ → ●
Specifications are subject to change without notice.
3. Specifications
G
B
GB-3
BC3450DW / BC4350DW
BC3450DW_4350DW_GB_cs5.indd 3 17/09/05 17:04
