•Always be sure to stop the engine before
inspecting the brushcutter for problems
or performing maintenance.
• Never alter the brushcutter or take the
engine apart.
•When replacing parts, always be sure to
use only RedMax products or products
which have been certified by RedMax for
use with the RedMax brushcutter.
• Things to check before using
brushcutter
■ REFILLING TRIMMING LINE
1. For replacement line, use a diameter of
.095in (2.4mm). The spool is capable for a
line upto 27ft (8m) on the 4” head, and 46ft
(14m) on the 6” head. Avoid using a larger
line as it may cut down the trimming
performance. For safety reasons, do not
use metalreinforced line.
2. Pinch the slotted area on the both sides of
the spool housing to unhook the bottom
cap.
3. Take out the spool and pull off the old line.
Put one end of new line through the spool
holes and pull it until the length is equal
between each part of the line.
4. Wind up the line in the correct as indicated
on the spool.
5. Hook each end of the line in the slot on
the edge of the spool, and then put the
ends through the eyelets on the housing.
Make sure that the spring and the washers
are in place.
6. While holding the spool against the
housing, pull the line ends to release them
from the slot.
7. Line up the slot on the bottom cap with the
hook on the housing, press the cap
against the housing until it clicks.
•Make sure that the engine has stopped
and is cool before performing any
service to the brushcutter. Contact with
moving cutting head or hot muffler may
result in a personal injury.
■ AIR FILTER
• The air filter, if clogged, will reduce the
engine performance. Monthly check and
clean the filter element in warm, soapy
water as required. Dry completely before
installing. If the element is broken or
shrunk, replace with a new one.
22
Maintenance
Maintenance, replacement, or repair of
the emission control device and systems
may be performed by any non-road
engine repair establishment or individual.
