Fig.1 DRIVE UNIT BC3401DL (S/N 60200000 and up)
Key# Description Part Number Q'ty
1 HOUSING 4050-11110 1
2 CAP 4050-11150 1
3 JOINT 4050-11210 1
4 ABSORBER-F 4050-11250 1
5 ABSORBER-R 4050-11260 1
6 BOLT 01252-30530 4
7 BOLT 01252-30630 1
8 BOLT 01252-30510 1
9 DRUM, clutch 848-B81-51A1 1
10 BEARING T3149-11350 1
11 SNAPRING 04065-03515 1
12 SNAPRING 04064-01510 1
13 BOLT 6468-91150 4
14 PIPE COMP. 1440x26xT2 4001-12100 1
15 GRIP T3217-14110 1
DRIVE SHAFT 1480x8
16 4050-12211 1
Spline ø8x9 teeth
17 HANGER ASS'Y 6520-17100 1
18 • HANGER 6520-17110 1
19 • CLAMP 6520-17120 1
20 • SPACER 6520-17130 1
21 • SCREW 0263-90525 1
22 LEVER ASS'Y 848-8R2-0352 1
23 • LEVER ASS'Y 848-8R2-0332 1
24 • • COVER COMP. 848-8RA-0350 1
25 • CORD(A), black T3003-14420 1
26 • CORD(B), red T3003-14430 1
27 CABLE COMP. 1855-82100 1
28 TUBE T3003-14510 1
29 GEARCASE ASS'Y T3003-13001 1
30 • GEARCASE 3541-13194 1
31 • BEARING 06000-06000 1
32 • BEARING 06000-06201 1
33 • SEAL 3180-13141 1
34 • SNAPRING 04065-03212 1
35 • BOLT 01252-30510 1
36 • FITTING, grease 3199-13350 1
37 • WASHER 01641-20608 1
38 • SHAFT 4050-13210 1
39 • GEAR 3180-13220 1
40 • WASHER 3310-43210 1
41 • WASHER 01643-30823 1
42 • BOLT, LH 3579-33260 1
43 • PINION 3541-13311 1
44 • BEARING 06001-06000 1
45 • BEARING 06000-06000 1
46 • SNAPRING 3180-13330 1
47 • SNAPRING 04065-02612 1
48 • BOLT 3540-13260 1
49 • HOLDER(A) 3541-13241 1
50 • HOLDER(B) 3541-13251 1
51 HANDLE ASS'Y 6462-14100 1
52 • HANDLE 6462-14310 1
53 • CLAMP 6462-14320 1
Key# Description Part Number Q'ty
54 • SCREW 0263-90535 4
55 GUARD ASS'Y 6358-24002 1
56 • GUARD COMP. 6358-24102 1
57 • • BLADE 6041-24140 1
58 • • NUT 3320-15310 2
59 • • SCREW 0263-30512 2
60 • CLAMP 3541-24121 1
61 • BOLT 3540-24130 2
62 • WASHER 0290-20615 2
63 SHAFT 6041-99220 1
64 COM.TAP.HEAD 6" PT100 1
65 • CASE 6041-99112 1
66 • CORD HOLDER 6041-99141 1
67 • COVER 6041-99130 1
68 • PLATE 3268-15150 1
69 • SPRING 6041-99162 1
70 • PLATE 3268-15170 1
71 • CORD 6041-99181 1
72 • SPACER 6460-15210 1
73 HARNESS ASS'Y 6565-95201 1
74 • HOOK COMP. 6565-17211 1
75 • PLATE 6565-17220 1
76 • HANGER COMP. 6565-95230 1
78 • PROTECTOR 6565-17200-02 1
79 TOOL SET 3532-91000 1
80 • SCREW DRIVER 1030-91340 1
81 • SOCKET 3239-91310 1
82 • WRENCH 09007-00425 1
83 • WRENCH 09007-00528 1
84 • BAR 3540-91110 1
85 • SPANNER 3540-91120 1
86 GOGGLE 6242-92110 1
87 NAME PLATE 848-B70-90R2 1
88 PLATE 3553-11550 1
27
