Zenoah BC4401DW - Page 33

 33 
Fig.4 ENGINE UNIT BC4401DW
(S/N 60200000 and up)
Key# Description Part Number Q'ty
1 CYLINDER 848-G6D-12A0 1
2 BOLT 1850-12130 4
3 GASKET, base 4500-13120 1
4 CRANKCASE COMP. 4500-21101 1
5• PIN 2629-21130 3
6 GUARD 4500-22110 1
7 SCREW 0263-90514 1
8 GASKET, case 4500-21140 1
9 BEARING 06030-06201 2
10 OIL SEAL 4810-21210 1
11 OIL SEAL 1650-21220 1
12 BOLT 01252-30530 4
13 SNAP RING 04065-03212 1
14 PISTON 4500-41110 1
15 RING 1400-41220 2
16 PIN 2850-41310 1
17 RING 1300-41320 2
18 BEARING T2100-41410 1
19 WASHER 2850-41510 2
20 CRANKSHAFT COMP. 4500-42000 1
21 SHOE, clutch 4500-51111 2
22 SPRING 4500-51220 1
23 SCREW 1200-51211 2
24 WASHER 1200-51230 2
25 WASHER 1200-51241 2
26 ROTOR T1153-71110 1
27 COIL ASS'Y T1153-71200 1
28 • CORD 4500-71220 1
29 • CAP 2616-71320 1
30 • PIN T1153-71250 2
31 • GROMMET 5500-72130 1
32 • CAP, plug 5500-72110 1
33 • SPRING 5500-72120 1
34 • TUBE T1512-71320 1
35 BOLT 3350-14150 2
36 NUT 1650-43230 1
37 KEY 1000-43240 1
38 MUFFLER ASS'Y T1007-15100 1
39 • ARRESTER 1601-15120 1
40 BOLT 01252-30565 2
41 BOLT 3310-31720 1
42 GASKET, muffler 4700-15211 1
43 PLATE, muffler 4500-15221 1
44 SCREW 0263-90514 1
45 COVER T1117-31111 1
46 BOLT 3310-12281 4
47 PLATE 4500-31210 1
48 COVER 4500-32110 1
49 SCREW 4500-32120 4
50 GUARD 4500-32210 1
51 SPARKPLUG RCJ6Y 3699-90419-20 1
52 GROMMET 1852-72121 1
53 CORD T1153-71240 1
54 CORD, earth T1006-73230 1
55 CLAMP 848-8K4-0010 1
56 RECOIL ASS'Y 4500-75100 1
57 • REEL 4500-75120 1
58 • SCREW 4500-75150 1
59 • SPRING, spiral 1850-75130 1
60 • COLLAR 4500-75180 1
Key# Description Part Number Q'ty
61 • ARM 4500-75190 1
62 • ROPE 4500-75160 1
63 • KNOB 1140-75320 1
64 • PLATE, stopper 5500-75170 1
65 PULLEY 4500-75210 1
66 SCREW 4500-75511 4
67 COLLAR 4700-75310 1
68 INSULATOR 4500-13161 1
69 SCREW 4500-13181 2
70 GASKET, insulator 4500-13150 1
71 GASKET, carburetor 4500-13130 1
72 CARB ASS'Y WYJ-219A T1007-81000 1
73 • REBUILT KIT 5602-06030 1
74 • • BODY ASS'Y 1850-81450 1
81 • • GASKET KIT 5602-06020 1
86 • BODY, purge 1850-81490 1
87 • COVER, pump 1850-81520 1
88 • PUMP, priming 1751-81510 1
89 • JET #45 T1007-81250 1
90 • O-RING 1751-81240 1
91 • RING 1751-81130 1
92 • SWIVEL 1881-81140 1
94 • SCREW 1752-81110 2
95 • BRACKET 5500-81120 1
96 • NUT, adjuster 1751-81180 1
97 • SCREW, adjuster 5730-81170 1
98 • RING 1881-81130 1
99 • SCREW 1850-81530 4
100 • WASHER 5500-81160 1
101 SCREW 0263-90550 2
102 BODY ASS'Y T1184-82101 1
103 • PLATE, choke T1184-82130 1
104 • LEVER, choke 4500-82140 1
105 • SCREW 2630-33610 1
106 ELEMENT 4500-82170 1
107 COVER ASS'Y 4500-82202 1
108 • KNOB 5500-82221 1
109 TANK ASS'Y T1015-85004 1
110 • CAP ASS'Y T1015-85202 1
111 • • HOLDER ASS'Y 4500-85300 1
112 • • FILTER 5601-85260 1
113 • • PACKING 4500-85220 1
114 • • STOPPER 4820-85260 1
115 • PIPE COMP. T1015-85300 1
116 • FILTER ASS'Y 3302-85400 1
117 • CLIP 1260-85460 1
118 SCREW 0263-90525 4
119 LABEL, cover T1716-31120 1
120 GUARD T1184-31911 1
121 COVER 4500-81910 1
