Zenoah G320RC User Manual

2) SPECIFICATIONS AND TECHNICAL DATA
Items Unit G320RC Remarks
Bore x Stroke mm 38 x 28
Displacement cm
3
31.8
Effective Compression Ratio 9.7
Type Walbro WT
Carburetor
Venture(mm) ø13.5
Starting Recoil Starter
Type TCI
Ignition
Timing BTDC 30°/8000rpm
Standard CMR7H NGK
CR8HIX
with Terminal Nut
Option(Hot Type) CMR6H ↑
Clutch Engagement Speed rpm 6000 STD Spring
No load max Speed rpm 20000
Idling Speed rpm 4000
Max. Net Power kW/rpm 2.40/13000
Max. Net Torque N.m/rpm 2.00/9000
Fuel Consumption g/kW·h 519
Carburetor H 1 7/8 ± 1/4
Standard setting L 1 3/8 ± 1/4
11
MAINTENANCE
↑
Option(For Race)
Spark Plug

Zenoah G320RC Specifications

General

Engine Type	G320RC
Displacement	31.8cm3
Carburetor Type	WT-1107
Spark Plug	NGK CMR7H
Spark Plug Gap	0.65mm
Clutch Engagement	6000rpm (STD Spring)
Rotating Direction	Counter-Clockwise (View From PTO)

Weight and Dimensions

Overall Size (L x W x H)	167 x 216 x 197mm
Weight	2.30kg
