Zenoah G320RC User Manual

• Mix gasoline (octane over 95) and high grade 2 cycle engine oil (mixing use type;
JASO FC grade or ISO-L-EGC grade) at mixing ratio 25:1.
• The mixing ratio is according to the oil recommendation.
[ NOTE ]
1) Gasoline may contain maximum of 10% Ethanol (grain alcohol) or up to 15% MTBE
(Methyl tertiary-butyl ether).
Gasoline containing Methanol (Wood Alcohol) is NOT approved.
FUELING SYSTEM
6
SAFETY PRECAUTIONS
overly long sleeves, neckties and the like. Failure to do so could result
in injury.
• When mounting the engine to a model, make sure to follow the model’s
operating manual. If necessary, reinforce the engine mounting unit and
the peripheral parts.

Zenoah G320RC Specifications

General

Engine Type	G320RC
Displacement	31.8cm3
Carburetor Type	WT-1107
Spark Plug	NGK CMR7H
Spark Plug Gap	0.65mm
Clutch Engagement	6000rpm (STD Spring)
Rotating Direction	Counter-Clockwise (View From PTO)

Weight and Dimensions

Overall Size (L x W x H)	167 x 216 x 197mm
Weight	2.30kg
