Zenoah G320RC User Manual

7
FUELING SYSTEM
2) Gasoline is very flammable. Avoid smoking and any fires near fuel.
3) To prevent all possible problems on fueling system, make sure to use the fuel filter
which has more than 300 mesh or equivalent and gasoline proof rubber pipe or
equivalent.
Incorrect fuel filter may cause engine trouble like fuel passage stuffing in carburetor,
or piston surface scratching etc.
4) When fueling, make sure that no fuel touches the hot parts.
5) Assemble the fuel line so that it does not touch the hot parts. Also, check that there
is no fuel leakage due to cracks, or hardening.
6) The picture below shows the tank dimensions for use with the 1799-85400 PIPE
COMP.
Tank Dimensions

Zenoah G320RC Specifications

General

Engine Type	G320RC
Displacement	31.8cm3
Carburetor Type	WT-1107
Spark Plug	NGK CMR7H
Spark Plug Gap	0.65mm
Clutch Engagement	6000rpm (STD Spring)
Rotating Direction	Counter-Clockwise (View From PTO)

Weight and Dimensions

Overall Size (L x W x H)	167 x 216 x 197mm
Weight	2.30kg
