Savona, Anzio, Ravenna, Roma Use, Care, and Installation Guide
ZSA, ZAN, ZRV, ZRO
WALL
CORE
Installation Instructions
ZAN Hood Specications
STANDARD
min. ducted - 27”
min. recirc. - 31”
max. - 48
-1/2
Z1C-00AN, Z1C-00ANBS
EXTENSIONS
min. ducted - 43”
min. recirc. - 47”
max. - 81”
6-1/417-7/8
1
-3/16
(24”) 23-7/8, (30”) 29-7/8”, (36”) 35-1/2
10-3/8
6”
3-15/16
1”
1”
1
-3/16
9-1/2
10-5/8
22
-1/16
5-5/16
TOP
FRONT SIDE
