Twister & Tornado I Use, Care, and Installation Guide
TWISTER &
TORNADO I
INSERT
CORE
Installing the Filters, FIG. I:
1. Place the back of filter into the back of the power pack.
2. Pull the filter latch while pivoting the filter upwards into
the power pack.
3. Push filter all the way up and lock into place by
releasing filter latch.
Maintenance
1
3
2
FIG. I
LumiLight LED
In the unlikely event that your LumiLight LED fails, please
contact Zephyr to order replacement parts.
See the list of parts and accessories page for part numbers
and contact information.
LED Removal (FIG. J):
1. Remove filters.
2. Disconnect LED light quick connector.
3. Push in the two side clips on the ends of the LED light.
4. Push LED light through the light panel opening.
Push the clip
FIG. J
