60
40. Remove the Ports. Label them so you can easily put them back in the same orientation!
188
188
41. Installing the Front: Use both clamps to squeeze the Front tight against the cabinet Top.
189
From
the rear, run a wood screw in through the cleat and spin it a few times with a Philips screw driver
to mark the Front.
190
Repeat for all four cleat holes.
189 190
42. Remove the Front and drill four pilot holes 5/64 x ½” deep in the back side of the Front.
191
191
To Next Page
