61
43. Apply glue to the cleats and the underside of the Top, where the Front will touch them.
192
Fit the
Front back into place, clamping it to the Top as before.
193
Using a screw driver or cordless screw
gun, run four wood screws #6x1-1/4” through the cleats and into the Front.
194
192 193
194
44. Re-drill the six little holes in the Ports with the 9/64” bit and countersink them.
195
195
Glue the LOWER PORT ONLY into place. Apply glue to the cabinet bottom and to the cleats just
where the lower Port will touch them. Fit the lower port back into the cabinet, being careful to
match up your markings.
196
Clamp the lower port tight to the cabinet bottom, and screw it tight to
the cleats with two wood screws.
197
Do NOT glue or install the upper port!
196 197
