7. Use the hammer to tap the four t-nuts (Part # NU03) into the four holes near the round cutout.
Keep tapping until the t-nuts are flat against the board.
251
8. Paint the side of the baffle board with the t-nuts and the inside surface of the round cutout flat
black. No other sides need to be painted.
252
Allow to dry thoroughly! Go work on the cabinet
while you are waiting.
9. Now it is time to put on the grill cloth. Attaching grill cloth in a way that looks nice is not
an easy task. There are two goals to keep in mind in working with grill cloth: 1) keep the
lines straight; and 2) make the grill cloth tight. There are several different techniques for
accomplishing these two goals, but the process described here has worked well for us. If you
aren’t confident about doing this step, call your local upholstery shop and they might be able to
help you out.
