9
J1 J2 KN05 D1 VR1
R1, R6, R11 R5, R9, R10 R3, R8 R4 R7, R14, R17
R16 R2 R15, R12 R13 SK05
SK10 S1
In the Hardware bag:
Part # Description Notes Qty
CB20 Solder Lug
1
CH05 Isolation Fin
2
GR02 Rubber Grommet
4
NU10 Keps Lock Nut M3
5
SC38 Philips Machine Screw – Pan head M3x6
17
SC63 Philips Sheet Metal Screw - Pan head 8x1/2” Assembling the chassis
4
SC68 Philips Sheet Metal Screw - Pan head 10x3/8 Attaching the fins
4
SC69 Philips Sheet Metal Screw - Flat head 6x1-1/4 Installing the chassis in the cabinet
4
SP11 Nylon Hex Standoff M3x12
6
WA07 Lock Washer M3
6
CB20 CH05 GR02 NU10 SC38
