Controls and Components
3.3
A. Mirrors
This motorcycle is equipped
with convex mirrors. A
convex mirror has a curved surface. Convex mirrors
offer a greater field of view than a similar flat mirror.
However, the greater field of view makes objects
seem further away than they really are. Care must be
used when judging the distance of objects seen in
these mirrors.
B. Key S
witch/Steering Lock
For description and operation see
“Key
Switch/Steering Lock Positions”, on page 4-4.
C. Da
sh
For description and operation see
“Dash Overview”,
on page 3-8.
D. Ca
vity for Accessory 12 Volt Socket
Location for Zero dealer-installed 12 volt accessory
socket.
E. F
ront Brake Fluid Reservoir
For description and operation see “Brakes”, on
page 5-9.
F. Right Handlebar Control
For description and operation see
“Handlebar
Controls”, on page 3-16.
G. Fr
ont Brake Lever
For description and operation see
“Handlebar
Controls”, on page 3-16.
H. Th
rottle Control
For description and operation see“Handlebar
Controls”, on page 3-16.
I. Motor Stop Switch
For description and operation see
“Handlebar
Controls”, on page 3-16.
J. T
ank Bag Lock
Lock for motorcycle tank bag see
“Tank Bag”, on
page 3-21.
K. L
eft Handlebar Control
For description and operation see
“Handlebar
Controls”, on page 3-16.
Zero Owner's Manual (S and DS).book Page 3 Tuesday, January 20, 2015 2:37 PM
