Controls and Components
3.5
A. Headlight
Fo
r headlight operation, see Handlebar Controls”, on
page 3-16.
Fo
r headlight bulb replacement, see “Headlight Bulb
Replacement”, on page 5-17.
Fo
r headlight alignment, see“Headlight Alignment”,
on page 5-16.
B. Fron
t Turn Signal
For turn signal operation, see Handlebar Controls”,
on page 3-16.
Fo
r turn signal light bulb replacement, see “Turn
Signal Light Bulb Replacement”, on page 5-19.
C. AC Cha
rger Power Connection
For description and operation, see Power Pack”, on
page 4-5.
D. Brake/Tail Light
For brake/tail light bulb replacement, see
“Brake/Tail
LED Replacement”, on page 5-19.
E. Re
ar Turn Signal
For turn signal operation, see
Handlebar Controls”,
on page 3-16.
F. Kicks
tand
The kickstand swings out from the side and supports
th
e motorcycle when parked. The key switch should
be in the OFF position when parked.
G. Kicks
tand Switch
This switch is a safety feature
that prevents motor
operation when the kickstand is down. If the kickstand
were down when riding it could contact the ground
causing you to lose control of the motorcycle and
cause personal injury.
CAUTION: Park only on a flat firm surface, otherwise the
motorcycle could fall over causing damage.
H. Integrated Power Pack Charger
For description and operation, see
Power Pack”, on
page 4-5.
