Controls and Components
3.7
A. Rear Break Fluid Reservoir
See “Rear Brake Fluid Reservoir”, on page
5-10.
B. Auxiliary Power Pack Charging Connection For
description and operation see
“Quick Charging (Off
Board Accessory Charger)”, on page 4-10. The
auxiliary connector is located above the motor.
C. Power Pack
For description and operation see
“Power Pack”, on
page 4-5.
D. Re
ar Brake Pedal
The rear brake pedal controls the rear brake when the
pe
dal is pressed. When braking, the throttle should be
in the closed position. The brake light illuminates
when the rear brake pedal is applied.
E. Br
ushless Motor Controller
Precisely “meters” the flow of electricity from the
po
wer pack to the motor according to the action of the
throttle and surrounding conditions.
F. Dr
ive Belt Tension Adjuster
See “Checking Drive Belt Tension”, on page
5-14 for
additional information.
Zero Owner's Manual (S and DS).book Page 7 Tuesday, January 20, 2015 2:37 PM
