Controls and Components
3.11
A. Left Indicator Turn Signal
An arrow on the lower dash flashes green
in the same direction as selected by the
turn signal switch. This arrow
remains
flashing until the turn signal request has been
canceled.
B. Sy
stem Warning Indicator
If a fault has been detected, count the
number of times the red LED flashes. See
the
table on “System Warning Indicator”,
on page 6-2.
C. T
emperature Lamp
This flashes in the event that you exceed
the motorcycle’s performance capabilities.
T
he temperature warning lamp indicates
the temperature of the motor, controller temperature,
or the battery over/under temperature. See
“Temperature Indicator”, on page 4-14.
D. Armed Indicator
Indicates the motorcycle is live
or ready to
move if the throttle is actuated. For
troubleshooting, see
“Troubleshooting
Your Motorcycle”, on page 6-1.
E. ABS (Anti-Lo
ck Brake System) Indicator
The indicator illuminates when the key is
in the ON p
osition. The light will extinguish
when the motorcycle exceeds 3 mph
(5 km/h). Unless there is a fault, the indicator will stay
of
f until the key is cycled off and back to the ON
position again. See “ABS (Anti-lock Brake System)”,
on page 4-15 for more information.
F. Charging Indicator
Flashes slowly when the motorcycle is
accepting a charge. The indicator flashes
rap
idly when a charging error is detected.
The indicator is solid green when the battery is
completely charged.
G. High Be
am Indicator
When the headlight high beam is on, this
indicator illuminates blue, and remains on
un
til the high beam is turned off.
H. Rig
ht Turn Signal Indicator
An arrow on the lower dash flashes green
in the same direction as selected by the
turn signal switch. T
his remains flashing
until the turn signal request has been canceled.
