Zero Zone RVZC30 - Moving Cases

MOVING CASES
The Back-to-Back cases are shipped with wood planks that allow the use of pipe rollers. These wood planks should be removed after the
case is moved to its nal location (Figure 6 on page 11).
The RVCZ and RVCC and BB cases have steel protective support plates under the ends (not under insulated dividers). These are
designed to protect the end from Johnson Bar damage.
Use the following methods to move the cases:
MODEL
FORK LIFT
FROM ENDS
JOHNSON
BAR
FURNITURE
DOLLY
PIPE
ROLLERS
SAFE (CASE)
JACKS
RVZC30 & RMZC24
   
RVZC BB
    
RVZC WA
*  
1-Door RVZC
*    
RVCC30 & RMCC24
   
RVCC BB
    
RMCC WA
  
1-Door RVCC
*    
* Fork lift from rear
Care should be taken when moving the cases. The doors should be secured so they cannot open while the case is moved.
Only experienced certied fork truck drivers should use fork trucks to move the cases. The case should only be lifted off the oor as high
as necessary for transport. The fork truck should be driven slowly avoiding any abrupt motions or bumps.
The cases have steel protective support plates under the ends (not under insulated dividers). These are designed to protect the end
panel from J-bar damage.
Care should be taken when moving the cases. The doors should be secured so they cannot open while the case is moved.
Only experienced certied forklift drivers should use forklifts to move the cases. The case should only be lifted off the oor as high as
necessary for transport. The forklift should be driven slowly, avoiding any abrupt motions or bumps.
The following forklift dimensions must be maintained to avoid damaging the case when it is lifted:
2-DOOR CASES
Forks must extend from 26" to no more than 30" under the case.
3-DOOR CASES
Use 48" long forks!
Forks must extend from 39" to no more than 43" under the case.
4 & 5-DOOR CASES
Use 48" long forks!
Fork blades wider than 4" will not t in the bases.
