Zerova DB Series - Product Specifications; Product Specification Details

3
2. Specification
2.1 Product Specification
Model Name
DBWU182XXXseries
AC
INPUT
Voltage Rating
1Φ277Vac (+10%, -15%)
Max. Input Current
10.75A
Electrical Distribution
1P+ N+ PE (Wye configuration)
Power Grid System
TN/TT
Frequency
50/60Hz
Max. Input Power
2.53KVA
Power Factor
> 0.99
Efficiency
> 94%, at optimize V/I point
DC
INPUT
Voltage Rating
300~825Vdc, 30kW@650Vdc ~
825Vdc when input voltage down
to 300Vdc the output power is
14KW(per module)
DC
OUTPUT
Maximum Output Power
180 kW
Simultaneously output
mode
0% , 50% , 100%
*Each connector will get 50%
output power when plug in
simultaneously; And one
connector will get 100% when
another connector finish the
charging session or only this
connector is plugged in.
Voltage Accuracy
±2%
Current Accuracy
±2%
Electrical Isolation
Isolation between Input and Output
