10
IV Operation
3. Gear shift operation
CAUTION. Make certain that control rod or cable is easily movable.
3.1 Lever travel: see Fig. 3
Minimum travel of gear shift lever (O-A=O-B) must be 35 mm (1.3/8") for outer pivot point
and 30 mm (1.3/16") for inner pivot point.
3.2 Lever position:
In neutral position perpendicular to control rod or cable. Gear shift lever can be fixed in any
position by means of clamping screw. Minimum distance between gear shift lever and cover
0.5 mm (0.02"). Opening or loosening of cover requires renewed adjustment (by specialized
personnel only).
3.3 Regular checks
are required to ensure the strict observance of item 3.1 and 3.2.
