13
Mounting and Balancing
Installing TransMount Wrist Rest 2S and TransMount Extendable Sling
Grip 2S
(hereinafter referred to as “Sling Grip” and “Wrist Rest” )
Installing Sling Grip
Alig
n the installation screw of the sling grip with the installation screw hole ①,
adjust the sling grip to the appropriate position and tighten the screw ②. Rotate the
sling grip to the far right ③, and tighten the sling grip lock screw after adjustment is
completed ④. The sling grip can also be rotated to the far left and adjusted for dual-
hand use.
①
②
⑤
⑥
④
③
Dual-Hand Mode
Sling Mode
