11
How to Use
Lock Mode (L):
The three motors are all locked and won't follow the movement of the stabilizer
handle. Push the joystick up/down and left/right to control the tilt axis and pan axis.
Follow Mode (F):
The roll axis motor is locked. The tilt axis and the pan axis motor follow the
movement of the stabilizer handle. Push the joystick up/down and left/right to control
the tilt axis and pan axis.
Tilt Axis
Roll Axis
Pan Axis
Tilt Axis
Roll Axis
Pan Axis

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Zhiyun SMOOTH - Q3 and is the answer not in the manual?

Zhiyun SMOOTH - Q3 Specifications

General IconGeneral
CategoryGimbal Stabilizer
Battery LifeUp to 15 hours
Charging Time3 hours
Weight340g
BrandZhiyun
ModelSMOOTH-Q3
Type3-Axis Gimbal
Battery Capacity1300mAh
CompatibilitySmartphones
Stabilization3-Axis
MaterialPlastic
Roll Mechanical Range320°
Rolling Angle-170° to +170°
Panning Angle-150° to +150°
Dimensions45 x 154 x 180 mm (folded)
