Product model：SM113
Product Specifications
Min. Standard Max. Remark
Operation Voltage 6.5V 7.4V 8.4V
Operation Current 70mA - 2500mA
Charging Voltage 4.5V 5V 5.5V
Charging Current - - 1200mA
Following Deviation in
Static State
±0.01° - ±0.04°
Following Deviation in
Motion State
±0.05° ±0.1° ±0.3°
Tilt Mechanical Range -260° - 80°
Roll Mechanical Range -170° - 170°
Pan Mechanical Range -150° - 150°
Operation Temperature -10℃ 25℃ 45℃
Charging Temperature 0℃ 25℃ 40℃
Battery Capacity - 1300mAh -
Battery Runtime - 7h 15h Lab Data
1
Charging Time - 3h - Lab Data
2
Valid Payload 150g - 280g
Mounting Clamp
Supporting Range
55mm - 90mm
Smartphone Thickness 7mm~10mm
Bluetooth Bluetooth 4.2
Equivalent isotropically
radiated power(EIRP)
<3dBm
Operation Frequency 2.402GHz~2.480GHz
Compatible Models
Smartphones that their width is within the holder's
capable width.
