Item Test Item Specifications Remarks.
OPERATION PANEL
Power Button
Tact SW (any buttons
except Power Button)
Timer Button
Once Power Button is pressed, buzzer A sounds and operation starts. When pressed
again, it extinguishes the flame (lock type).
When Tact button is pressed, buzzer A sounds.
In operation
1) If current time and timer are not set:
Timer Button will not operate.
2) If current time is already set and timer is not set:
Operation stops, Information Display bar indication is on, colon lamp turns on, and
Timer Lamp flashes. If UP or DOWN Button is not pressed within 10 sec., a timer
error will occur. If UP or DOWN is pressed while Timer Lamp is flashing (within 10
sec.), the lamp flashes, setting is 0:00, and setting can be changed. After 10 sec.,
Clock Lamp and Timer Lamp will turn on, and timer will be in standby.
3) If current time and timer are already set:
Operation stops, timer indication flashes, and Timer Lamp flashes. While Timer
Lamp is flashing (10 sec.), timer setting can be changed. After 10 sec., Clock Lamp
and Timer Lamp go on, and timer will be in standby.
During stop
4) If current time and timer are not set:
Timer Button will not operate.
5) If current time is already set and timer is not set:
Information Display bar indication is on, colon lamp turns on, and Timer Lamp
flashes. If UP or DOWN Button is not pressed within 10 sec., setting returns to
current time. If UP or DOWN Button is pressed while Timer Lamp is flashing (10
sec.), Information Display is indicated as 0:00 and setting can be changed. After 10
sec., setting returns to current time. Also, when Power Button is turned on while
Timer Lamp is flashing, setting returns to 3) above and timer will be in standby.
6) If current time and timer are set:
Timer setting flashes, and Timer Lamp flashes. While Timer Lamp is flashing (10
sec.), timer setting can be changed. After 10 sec., setting returns to current time.
When Power Button is turned on while Timer Lamp is flashing(10 sec.), setting
returns to 3) above and timer will be in standby.
3.3.7
3.3.7-1
3.3.7-2
3.3.7-3
