BURNING SYSTEM
(1) When the Power Switch is pressed, the Igniter is electrically generated to preheat
the Burner Bottom. The completion time of preheating is detected by electric timer,
of which standard time is approximately 90 sec. at a room temperature of 15 °C,
provided that it is approximately 180 sec. if the room temperature is lower than 6 °C.
In the case of the shortest time (for instance, when re-igniting shortly after
extinguishing burning), a shorter time of approximately 40 sec. is obtainable.
(2) Upon the completion of preheating, the combustion air is sent into the Burner, while
the fuel is sent from the Fuel Nozzle, at the same time. The fuel is instantaneously
evaporated and immediately ignited with the Igniter which has been red-heated at a
temperature of higher than 900 °C.
(3) After ignition, “Med-High” burning continues for approximately 40 sec., to raise the
temperature of the Burner, after which burning is automatically controlled for the
burning sequence of “High ↔ Med-High ↔ Med. ↔ Med.-Low ↔ Low. The Igniter
becomes off while the heater is in burning operation. The Burner bottom maintains a
high temperature burning of higher than 300 °C by receiving a high radiation heat
from the Burner Ring.
(4) When the Power Switch is pressed again, the burning will cease in around 5 sec.
The Circulation Fan will run for approximately 90 sec. and then stop automatically.
SPECIFICATIONS
Model SRE 156 SRE 166 SRE 176 SRE 250 SRE 260
Oslo, SRE 701,
SRE 702, SRE 703
Type Forced draft, unvented, pot type kerosene heater (forced convection type)
Ignition Electric
Fuel Kerosene
High 3000 W 3100 W 3700 W 4850 W 6000 W 3000 W
Heating
Power
Low 800 W 800 W 1050 W 1450 W 2450 W 800 W
Fuel
Max.
(High)
0.313 l/h 0.323 l/h 0.385 l/h 0.505 l/h 0.625 l/h 0.313 l/h
Consumption
Min.
(Low)
0.083 l/h 0.083 l/h 0.109 l/h 0.151 l/h 0.235 l/h 0.083 l/h
Fuel Tank Capacity Max. 5.4 lit. Max. 7.6 lit. Max. 7.6 lit. Max. 5.1 lit. Max. 7.1 lit. Max. 4.0 lit.
Burning Time 17-65 hrs. 23.5-91 hrs. 20-70 hrs. 10.5–35hrs. 11-28 hrs. 13-47 hrs.
Exterior Dimensions
W
(mm)
405 435 550 588 704 374
(including drip tray)
D
(mm)
295 315 322 320 355 280
H
(mm)
435 437 445 485 560 430
Weight 10 kg 11 kg 12 kg 15 kg 21 kg 9.5 kg
Voltage and Frequency 230V (50Hz)
Power Max. 980 W (A short time in the initial period of ignition)
Consumption Burning 32 W 32 W 28 W 38 W 44 W 32 W
Current Fuse 4 A
Safety Device Tip-over Switch
Ignition Safety Device
Burning Control Device
Safety Device for Power Outage
High Limit Switch (Overheat Protector)
Incomplete Combustion Preventive Device (Flame Rod, Burner Thermistor)
