nciMinSendTime SNVT_time_-
sec (107)
0 .. 65535,
0,1sec
2,0 sec Minimum time between send
actions
nciMaxSendTime SNVT_time_-
sec (107)
0 .. 65535,
0,1sec
60,0 sec Maximum time between send
actions for Nv (if no send ac-
tion occurs within this time,
one is generated)
nviAddrRelais SNVT_switch
(95)
.value 0...200,
255
.state 0,1
0
0
For internal ZIEHL-ABEGG
use only!
Required for MODBUS AUTO
addressing.
* Use nvoAlarm or nvoRelay for preference
** Not used, only for testing purposes/diagnostics
*** For internal ZIEHL-ABEGG use only
Alarm codes (nvoAlarm, nvoRelay)
error code Error description Reaction
128 no error
129 general error No specific description
131 motor over temperature (thermo-
stats)
Motor shuts down. After cooling, switching back on is
possible by enabling again or re-applying the mains
voltage.
132 Motor blocked Motor shuts down. Starting retried after approx. 1 mi-
nute.
134 Earth fault Motor shuts down. Switching back on is only possible
by re-applying the mains voltage.
135 Hall sensor error Starting retried after approx. 1 minute.
136 Overcurrent fault Motor shuts down. Starting retried after approx. 1 mi-
nute.
150 external communication error Motor continues running with last set values
158 Supply voltage too high (overvolt-
age)
Motor shuts down. Starting retried if undervoltage no
longer exists within 75 s. Otherwise fault message.
6 Enclosure
6.1 Technical data
Type Connection box ECblue (LON)
Part-No. 380100
Voltage supply 10 V DC, I
max
30 mA, from ECblue motor size B (IP20)
Transceiver TP/FT10
Communication Connection box - ECblue RS485
Electromagnetic compatibility Interference emission EN 61000-6-3 (domestic household applica-
tions)
Interference immunity EN 61000-6-2 (industrial applications)
Permissible ambient temperature 0...40 °C
Permissible temperature range for storage
and transport
-20...60 °C
Housing protection IP20 (in installed condition)
Weight 0.16 holder plate
Operating Instructions Connection box ECblue (LON) Enclosure
L-BAL-E268-GB 1630 Index 003 Part.-No.
9/10
