8.3 Menu group "INFO"
The number of menus depends on the selected operating mode.
Settings cannot be made in this menu group!
INFO
Mode
Display
4.00 4.01 4.02 5.00 5.01 5.02
Actual value after turning on the voltage or after exiting the setting menu using
the Esc key combination.
Δp
0 Pa
(0.000
in.wg)
0 Pa
(0.000
in.wg)
0 Pa
(0.000
in.wg)
- - -
qV - - -
0 m
3
/h
(0 cfm)
0 m
3
/h
(0 cfm)
0 m
3
/h
(0 cfm)
Display outdoor temperature
Outdoortemp. - -
15.0 °C
(59.0°F)
- -
15.0 °C
(59.0°F)
Active setpoint display (Setpoint 1 or Setpoint 2 depending on activation via
digital input or timer).
Setpoint 1 -
500 Pa
(2.000
in.wg)
500 Pa
(2.000
in.wg)
-
1185 m
3
/h
(697 cfm)
1185 m
3
/h
(697 cfm)
Setpoint control in operating modes with outdoor temperature compensation.
This function automatically changes the set and active Setpoint 1/2 propor-
tional to the measured outdoor temperature.
Setpoint Con-
trol
- -
254 Pa
(1.000
in.wg)
- -
593 m
3
/h
(349 cfm)
Air volume measuring range depending on sensor measuring range and K-
Factor
Range qV - - -
2371 m
3
/h
(1394 cfm)
2371 m
3
/h
(1394 cfm)
2371 m
3
/h
(1394 cfm)
Operating Instructions UNIcon CPG-..AVC Programming
L-BAL-E286-GB 1904 Index 004 Part.-No.
28/52
