Page #38 background imageLoading...
Page #38 background image
8.5.2 Limit message actual value
Menu overview
Function Designation
OFF
Actual Value
Fnc
OFF: no function
ON: limit message active
The values "Value min." and "Value max." can be set inde-
pendently of one another. The unit depends on the selected
operating mode (
4.. / 5.. ) and unit (metric / inch).
Depending on the operating mode, the message "Limit Pres-
sure" / "Limit AirVolume" appears in the display if the set limits
for the actual value are exceeded or not reached.
The message via the relay depends on the programmed
function (see IO Setup), with the factory setting (K1 function =
|
2K
|
, not inverted), the relay is de-energised in case of a
message (terminals 13 - 14 disconnected).
0 Pa / 0 m
3
/h
(in.wg / cfm)
Value min.
Work can be carried out with one as well as with both limit
indicators.
If the actual value undercuts the set value "Value min.", this is
reported until the set value (plus 5 % hysteresis) has been
exceeded once again.
If the actual value exceeds the set value "Value max.", this is
reported until the set value (minus 5 % hysteresis) has been
undercut once again.
0 Pa / 0 m
3
/h
(in.wg / cfm)
Value max.
2 s
Value delay
The indication is delayed by the time set.
Setting range: 0 - 120 sec.
Factory setting: 2 sec.
Information
Always set the value for "Value max." higher than the value for
"Value min.".
Operating Instructions UNIcon CPG-..AVC Programming
L-BAL-E286-GB 1904 Index 004 Part.-No.
38/52
