9 Enclosure
9.1 Technical data
Type CPG-200AVC CPG-1000AVC CPG-6000AVC
Part-No. 320075 320076 320077
Voltage supply 10...24 V DC (+20 %)
Protected against reverse polarity
@ U
S
10 V DC @ U
S
13...24 V DC
Max. load output 0...10 V
(short-circuit-proof)
0.3 mA 10 mA
Max. current consumption ca. 28 mA 28 mA
Pressure connections “+, -” Hose connectors d = 5 / 6 mm (0.20 / 0.24 inch)
Housing PC (polycarbonate)
Fire protection classification UL94V0
Use position vertical (measuring depends on position)
Protection rating IP54 according EN 60529
Weight approx. 250 g (0.55 lb)
Permissible ambient temperature -10...60 °C (14...140 °F)
Permissible medium temperature -10...70 °C (14...158 °F)
Permissible temperature range for
storage and transport
-30...70 °C (-22...158 °F)
Permissible rel. humidity 85 % no condensation
One-sided permissible overload 0.1 bar (80 in.wg)
Burst prssure at room temperature: 0.2 bar (80 in.wg)
at 70 °C (158 °F): 0.15 bar (60 in.wg)
Maximum cross section of terminals 1.5 mm
2
/ AWG16
Interference emission according EN 61000-6-3 (domestic household
applications)
Interference immunity according EN 61000-6-2 (industrial applications)
Operating Instructions UNIcon CPG-..AVC Enclosure
L-BAL-E286-GB 1904 Index 004 Part.-No.
49/52
