ZIMO MS440C - Random and Switch input sounds

MS - SOUND decoders MS440 to MS990 and MN - NON-SOUND decoders MN170 to MN340 Page 59
CV
Denomination
Value-
Range
Def
Description
#315
Random generator
Z1
Minimal interval
0 - 255
=
0 - 255 sec
1
The random generator generates internal pulses in irregular in-
tervals that are used to playback a sound file assigned to the
random generator. CV #315 defines the shortest possible in-
terval between two consecutive pulses.
Sound samples are assigned to the random generator Z1 with
the help of the CV #300 = 101 procedure, see above! By de-
fault, the compressor is assigned to Z1.
Special note to the random generator Z1: To start the air brake pump, which is optimized for Z1, immedi-
ately after the train stopped, the following settings are required:
CVs #315 and #316 have to be set on the same value (e.g. 30), and CV #154 has to have the value 16.
#316
Random generator
Z1
Highest interval
0 - 255
=
0 - 255 sec
60
CV #316 defines the maximum time interval between two con-
secutive pulses of the random generator Z1; the actually oc-
curring pulses between the values in CV #315 and #316 are
equally distributed.
#317
Random generator
Z1
Duration of playback
0 - 255
=
0 - 255 sec
5
The sound sample assigned to the random generator Z1 (most
often the compressor) is played back for the timespan defined
in CV #317.
= 0: Play back sound sample for the first time
#318
#319
#320
As above,
however…
Random generator
Z2
0 - 255
0 - 255
0 - 255
20
80
5
By default, Z2 is assigned for coal shoveling at stand-still.
#321
#322
#323
As above,
however…
Random generator
Z3
0 - 255
0 - 255
0 - 255
30
90
3
By default, Z3 is assigned for the injector at stand-still.
#324
-
#338
As above,
however…
Random generator
Z4 - Z8
0 - 255
0 - 255
0 - 255
At delivery this random generator is not used.
#341
Switch input 1
Duration of playback
SW version 5.00 and
higher
0 - 255
=
0 - 255 sec
0
The sound sample allocated to switch input 1 is played back
for the duration defined with this CV.
= 0: Play back sound sample for the first time
#342
Switch input 2
Duration of playback
SW version 5.00 and
higher
0 - 255
=
0 - 255 sec
0
The sound sample allocated to switch input 2 is played back
for the duration defined with this CV.
= 0: Play back sound sample for the first time
#343
Switch input 3
Duration of playback
SW version 5.00 and
higher
0 - 255
=
0 - 255 sec
0
The sound sample allocated to switch input 3 (as far as it is not
used as cam sensor) is played back for the duration defined
with this CV.
= 0: Play back sound sample for the first time
#392
Switch input 4
Duration of playback
SW version 5.00 and
higher
0 - 255
=
0 - 255 sec
0
The sound sample allocated to switch input 4 is played back
for the duration defined with this CV.
= 0: Play back sound sample for the first time
