ZIMO MS440C - Page 78

Page 78 MS - SOUND decoders MS440 to MS990 and MN - NON-SOUND decoders MN170 to MN340
CV
Denomination
Range
Default
Description
1 - 12
14 (FO0f)
15 (FO0r)
Bits 5 - 7:
0 - 7
Function output to be switched ON in reverse direction pro-
vided that both, the “F” and “M”-keys are ON (if bit #7 for
the M-key = 1, otherwise F-key ON is sufficient).
Bits 7, 6, 5 (7 possible values or zero):
Number of the applicable dimming CV. For example:
Bit 5 = 1 means dimming according to CV #508 etc.
3.17
#435
Swiss Mapping
Group 1
“A2” reverse
Bits 0 - 3:
1 - 12
14 (FO0f)
15 (FO0r)
Bits 5 - 7:
0 - 7
0
Bits 0 - 3:
Additional function output to be switched ON in reverse di-
rection provided that both the “F” and “M”-keys are ON (if
bit #7 for the M-key = 1, otherwise F-key ON is sufficient).
Bits 7, 6, 5 (7 possible values or zero):
Number of the applicable dimming CV. For example:
Bit 5 = 1 means dimming according to CV #508 etc.
3.17
#436 -
#441
. . . Group 2.
. . .
0
All 6 CVs in group 2 are defined the same way as the 6
CVs in group 1.
3.17
#442 -
#447
. . . Group 3.
. . .
0
All 6 CVs of the following groups are defined the same
way is the 6 CVs in group 1.
3.17
#448 -
#453
. . . Group 4.
. . .
0
. . .
3.17
#454 -
#459
. . . Group 5.
. . .
0
. . .
3.17
#460 -
#465
. . . Group 6.
. . .
0
. . .
3.17
#466 -
#471
. . . Group 7.
. . .
0
. . .
3.17
#472 -
#477
. . . Group 8.
. . .
0
. . .
3.17
#478 -
#483
. . . Group 9.
. . .
0
. . .
3.17
#484 -
#489
. . . Group 10.
. . .
0
. . .
3.17
#490 -
#495
. . . Group 11.
. . .
0
. . .
3.17
#496 -
#501
. . . Group 12.
. . .
0
. . .
3.17
#502 -
#507
. . . Group 13.
. . .
0
. . .
3.17
#508
#509
#510
#511
#512
Dimming values for
the
“Swiss Mapping”
Special configura-
tions
(0- 31)*8
(Only bits
3 - 7 are
used)
Bits 0 - 2
0
Each group-CV (i.e. #432, #433, #434, #435) can be linked
to one of these five dimming CVs.
This means that the function outputs shall be dimmed ac-
cordingly when switched on.
Value 0 = dark, value 31 = not dimmed.
Usable only with function outputs FO0 to FO13.
Bit 0 = 1: suppresses the lighting effect
Bit 1 = 1: Flashing effect
Bit 2 = 1: Inverted flashing
5.3
#513
Sound number F1
Sample number of function sound on F1
5.3
#514
Function sound F1
0 - 255
0
Volume adjustment
CV
Denomination
Range
Default
Description
5.3
#515
Loop info F1
Bit 0 to Bit2: Loop count 0-7
Bit 3 = 1: repeat when on (=active F-key) = sound
"loop".
Bit 4 = 1: play sound only if forward direction is present
Bit 5 = 1: play sound only if backward direction is
present
Bit 6 = 1: cancel when off (=deactivated F-key), =sound
"shorten
Bit 7 = 1: play sound only if drive and random sounds
are active (if F-button defined in CV #310 is
pressed/active)
5.3
#516
Sound number F2
Sample number of function sound on F2
5.3
#517
Function sound F2
0 - 255
0
Volume adjustment
5.3
#518
Loop info F2
Same as CV #515 but for F2
5.3
#519
Sound number F3
Sample number of function sound on F3
5.3
#520
Function sound F3
0 - 255
0
Volume adjustment
5.3
#521
Loop info F3
Same as CV #515 but for F3
5.3
#522
Sound number F4
Sample number of function sound on F4
5.3
#523
Function sound F4
0 - 255
0
Volume adjustment
5.3
#524
Loop info F4
Same as CV #515 but for F4
5.3
#525
Sound number F5
Sample number of function sound on F5
5.3
#526
Function sound F5
0 - 255
0
Volume adjustment
5.3
#527
Loop info F5
Same as CV #515 but for F5
5.3
#528
Sound number F6
Sample number of function sound on F6
5.3
#529
Function sound F6
0 - 255
0
Volume adjustment
5.3
#530
Loop info F6
Same as CV #515 but for F6
5.3
#531
Sound number F7
Sample number of function sound on F7
5.3
#532
Function sound F7
0 - 255
0
Volume adjustment
5.3
#533
Loop info F7
Same as CV #515 but for F7
5.3
#534
Sound number F8
Sample number of function sound on F8
5.3
#535
Function sound F8
0 - 255
0
Volume adjustment
5.3
#536
Loop info F8
Same as CV #515 but for F8
5.3
#537
Sound number F9
Sample number of function sound on F9
5.3
#538
Function sound F9
0 - 255
0
Volume adjustment
5.3
#539
Loop info F9
Same as CV #515 but for F9
5.3
#540
Sound number F10
Sample number of function sound on F10
5.3
#541
Function sound
F10
0 - 255
0
Volume adjustment
5.3
#542
Loop info F10
Same as CV #515 but for F10
5.3
#543
Sound number F11
Sample number of function sound on F11
5.3
#544
Function sound
F11
0 - 255
0
Volume adjustment
5.3
#545
Loop info F11
Same as CV #515 but for F11
5.3
#546
Sound number F12
Sample number of function sound on F12
5.3
#547
Function sound
F12
0 - 255
0
Volume adjustment
5.3
#548
Loop info F12
Same as CV #515 but for F12
5.3
#549
Sound number F13
Sample number of function sound on F13
