3.22 Special Effects for Function Outputs
(US and other lighting effects, smoke generators, uncouplers etc.)
Special effects can be assigned to a total of 10 function outputs with
CV’s #125, #126, #127 … #132, #159, #160
for F0fr., F0rear. FO1 ...... FO6 , FO7 , FO8
The values for these special effect CV’s contain the
actual 6-Bit special effects code and the 2-Bit directions code
Bits 1,0 = 00: bidirectional (active in both directions)
= 01: active in forward direction only (+ 1)
= 10: active in reverse direction only (+ 2)
Bits 7 ... 2 = 000000xx No effect, except for direction = (0), 1, 2 (bidirectional, forward, reverse)
= 000001xx Mars light + direction = 4, 5, 6 (bidirectional, forward, reverse)
= 000010xx Random flicker + direction = 8, 9, 10 (ditto, ditto, ditto)
= 000011xx Flashing headlight + direction = 12, 13, 14 …
= 000100xx Single pulse strobe + direction = 16, 17, 18
= 000101xx Double pulse strobe + direction = 20, 21, 22
= 000110xx Rotary beacon + direction = 24, 25, 26
= 000111xx Gyralite + direction = 28, 29, 30
= 001000xx Ditch light type 1, right + direction = 32, 33, 34
= 001001xx Ditch light type 1, left + direction = 36, 37, 38
= 001010xx Ditch light type 2, right + direction = 40, 41, 42
= 001011xx Ditch light type 2, left. + direction = 44, 45, 46
= 001100xx Uncoupler as defined in CV #115 = 48, 49, 50
automatic disengagement in CV #116
= 001101xx “Soft start” = slow power-up of function output = 52, 53, 54
= 001110xx Automatic stoplights for street cars,
stoplight-off delay, see CV #63. = 56, 57, 58
= 001111xx Function output turns itself off at speed >0 = 60, 61, 62
(i.e. turns off cab light when driving).
NOT for MX621 = 010000xx Function output turns itself off after 5 minutes = 64, 65, 66
(i.e. to protect smoke generators form overheating).
-“- = 010001xx As above, but after 10 minutes = 68, 69, 70
-“- = 010010xx Speed or load dependent smoke generation = 72, 73, 75
for steam engines as per CV’s 137 – 139 (i.e. pre-heating at
stand still, heavy smoke at high speed or high load). Smoke
turns off as per CV #353; function key has to be pressed to
reactivate smoke.
-“- = 010100xx Driving state-dependent smoke generation for diesel engines = 80, 81, 82
as per CV’s #137 – 139 (i.e. pre-heating at stand still, heavy
smoke during motor start-up sound and acceleration).
Synchronized control of fan connected to the fan output. Smoke
turns off as per CV #353; function key must be pressed to
reactivate smoke.
= 100010xx Slow fade in/out of a function output; useful for various = 88, 89, 90
lighting effects or motorized equipment (i.e. fan, snow blower). (SW version
Dimming time is set with CV’s #190 and 191. 33.10 and up)
 The effect-CV’s are also suitable for
direction dependent function outputs
without using a special effect (with effect code 000000).
EXAMPLE:
CV #127 = 1, CV #128 = 2, CV #35 = 12 (FO1, FO2 operate directional, ON/OFF with F1 key).
CV
Designation
Range
Default
Description
#125
1
Special effects
According to list above
for
function output F0 (front
headlight)
Effects can be further
adjusted and modified
with
CV’s #62 - 64
and
CV #115, #116
(for uncoupler).
0
Bits 1, 0 = 00: bidirectional (active in both directions)
= 01: only active in forward direction
= 10: only active in reverse direction
ATTENTION in case of CV #125 and #126: change
CV’s #33, 34.... if direction is wrong!
Bits 7, 6, 5, 4, 3, 2 = Effect-Code
EXAMPLES
You want : Program CV #125 to:
Mars light forward only - 00000101 = 5
Gyralite independent of direction - 00011100 = 28
Ditch type 1 left, only forward - 00100101 = 37
Uncoupler - 00110000 = 48
Soft start of output - 00110100 = 52
Automatic stop light - 00111000 = 56
Automatic cab light OFF - 00111100 = 60
Speed/load depen. smoke - 01001000 = 72
Speed/load depen. diesel smoke - 01010000 = 80
#126
Special effects
for
rear headlight
(default F0 reverse)
0
See CV #125 for details.
#125  Front headlight
#126  Rear headlight
#127 -
#132
Special effects for
FO1, FO2, FO3,
FO4, FO5, FO6
FO3 and up NOT for MX621
0
See CV #125 for details
#127  FO1 #128  FO2
#129  FO3 #130  FO4
#131  FO5 #132  FO6
#159,
#160
Special effects for
FO7, FO8
0
See CV #125 for details
#159  FO7 #160  FO8
ATTENTION: “Coupler” and “Smoke” effects could be
used with FO0 - FO6 have now moved to FO7 - FO8
with SW version 34 or higher.
#62
Effects modifications
0 - 9
0
Change of minimum dimming value
#63
Light effects
modifications
or
Stop light OFF delay
0 - 99
0 - 255
51
Tens digit: sets cycle time (0 - 9, default 5), or start-up
time during “soft start” with 001101 (0 - 0,9s)
Ones digit: extends OFF time
For stop light OFF delay (001110xx in CV #125, 126
or 127): Time in tenths of a second the stop lights re-
1
Note to ditch lights: Ditch lights are only active when headlights and function F2 (#3 on Zimo cab) are on, which is prototypical for North American railroads. The
ditch lights will only be working if the applicable bits in CV #33 and 34 are on (the definition in CV #125 - 128 in itself is not enough but a necessary addition).
Example: If ditch lights are defined for F1 and F2, the bits #2 and 3 in CV #33 and 34 have to be set accordingly (i.e. CV # 33 = 13 (00001101), CV #34 = 14
(00001110).
