Large-scale Decoder & Sound Decoder MX695, MX696, MX697, MX699 Page 17
Loco board LOKPL99 with solder pads,
for large-scale decoders MX699LS and MX699LV
When installing these loco boards, all wires (track, motor, speaker, bulbs...) are soldered to
the loco board and after that, the approrpiate decoder is plugged in.
Connection diagram for
loco board LOKPL99 (with solder pads)
62 x 40 x 10 mm
WILL BE ADDED LATER
NOTE: The servos are connected directly
to the decoder MX695. For this reason,
the loco board has special cut-outs
LOKPL99 
WILL BE ADDED LATER
WILL BE ADDED LATER
 Loco board LOKPL99 with
decoder MX699LS or –LV
plugged in
