5.16 “Unilateral Light Suppression”
This new feature (since SW version 30.7, expanded in 33.18), asked for by many users,
makes it possible to switch off all lighting on one side of a locomotive with the push of one
function key (usually on the “train side”, i.e. where cars are coupled to the locomotive).
CV
Designation
Range
Default
Description
#107
Light suppression
(i.e. front headlights
AND additionally de-
fined function output)
at
cab side 1 (front)
0 - 255
0
The value of this CV is calculated as follows:
The number of a function output (FO1…FO28) x 32
+ number of a function key (F1, F2…F28)
= Value of CV #107
Function Key: The key (F1…F28) which should turn off
ALL lights on the cab side 1 (front side) AND
Function Output: i.e. taillights on the same side.
#108
Cab side 2 (rear)
0 - 255
0
Same as CV #107 but for other locomotive side.
#109
Additional FU-output,
cab side 1
1 - 6
0
Fu-output turns off together with CV #107.
#110
Additional FU-output,
cab side 2
1 - 6
0
Fu-output turns off together with CV #108.
