ZIMO MX695 - Special Effects (US and Other Light Effects, Smoke Generator, Uncouplers Etc.)

Page 36 Large-scale Decoder & Sound Decoder MX695/6/7/9
5.22 Special Effects for Function Outputs
(US and other light effects, smoke generator, uncouplers etc.)
Special effects can be assigned to a total of 10 function outputs with
CV’s #125, #126, #127 … #132, #159, #160
for F0fr., F0rear. FO1 ...... FO6 , FO7 , FO8
The values that can be programmed into the effect CV’s consist of
the 6-bit - effects code and the 2-bit - directions code
Bits 1,0 = 00: bidirectional (active in both directions)
= 01: active in forward direction only (+ 1)
= 10: active in reverse direction only (+ 2)
Bits 7 ... 2 = 000000xx No effect, except for direction = (0), 1, 2 (bidirectional, forward, reverse)
= 000001xx Mars light + direction = 4, 5, 6 (bidirectional, forward, reverse)
= 000010xx Random Flicker + direction = 8, 9, 10 (ditto, ditto, ditto)
= 000011xx Flashing headlight + direction = 12, 13, 14
= 000100xx Single puls strobe + direction = 16, 17, 18
= 000101xx Double puls strobe + direction = 20, 21, 22
= 000110xx Rotary beacon simul + direction = 24, 25, 26
= 000111xx Gyralite + direction = 28, 29, 30
= 001000xx Ditch light type 1, right + direction = 32, 33, 34
= 001001xx Ditch light type 1, left + direction = 36, 37, 38
= 001010xx Ditch light type 2, right + direction = 40, 41, 42
= 001011xx Ditch light type 2, left. + direction = 44, 45, 46
= 001100xx Uncoupler as defined in CV #115, = 48, 49, 50
automatic disengagement in CV #116
= 001101xx “Soft start” = slow power-up of function output = 52, 53, 54
= 001110xx Automatic stoplights for street cars, = 56, 57, 58
stoplight-off delay, see CV #63.
= 001111xx Function output turns itself off at speed >0 = 60, 61, 62
(i.e. turns off cab light when driving).
= 010000xx Function output turns itself off after 5 minutes = 64, 65, 66
(i.e. to protect smoke generators form overheating).
= 010001xx as above, but automatic shut-off occurs after 10 min. = 68, 69, 70
= 010010xx Speed or last dependent smoke generation. = 72, 73, 75
for steam engines as per CV’s #137 - 139 (I.e. preheating during
standstill, heavy smoke at high speed or under heavy load.) Smoke
turns off as per CV #353; function key has to be pressed to
reactivate smoke.
= 010100xx Driving state-dependent smoke generation for diesel engines = 80, 81, 82
as per CV#137-139 (preheating during standstill, heavy smoke
during motor start-up sound and during acceleration Synchronized
control of fan connected to the fan output. Smoke turns off as per
CV #353; function key has to be pressed to reactivate smoke.
= 010110xx Slow fade in/out of a function output; useful for various = 88, 89, 90
lighting effects or motorized equipment (i.e. fan, snow blower). (SW version
Dimming time is set with CV’s #190 and 191. 33.10 and up)
 The effect CV’s are also suitable without using a special effect (with effect code 000000), for
direction dependent function outputs.
EXAMPLE:
CV #127 = 1, CV #128 = 2, CV #35 = 12 (FO1, FO2 operate directional, ON/OFF with F1 key).
CV
Designation
Range
Default
Description
#125
1
Special effects
American lighting ef-
fects as well as others
such as uncoupler,
smoke generator and
more
on
function output F0
(front headlight)
Effects can be further
adjusted and modified
with
CV’s #62 - 64
and
CV #115, #116
(for uncoupler).
0
Bits 1, 0 = 00: bidirectional (active in both directions)
= 01: only active in forward direction
= 10: only active in reverse direction
ATTENTION in case of CV #125 and #126: change
CV’s #33, 34.... if direction is wrong!
Bits 7, 6, 5, 4, 3, 2 = Effect-Code
EXAMPLES
You want : Program CV #125 to: Mars
light forward only - 00000101 = 5
Gyralite independent of direction - 00011100 = 28
Ditch type 1 left, only forward - 00100101 = 37
Uncoupler - 00110000 = 48
Soft start of output - 00110100 = 52
Automatic stop light - 00111000 = 56
Automatic cab light OFF - 00111100 = 60
Auto. smoke OFF after 5 min – 01000000 = 64
Auto. smoke OFF after 10 min – 01000100 = 68
Speed/load depen. smoke - 01001000 = 72
Speed/load depen. diesel smoke - 01010000 = 80
#126
Special effects for
rear headlight
(default F0 reverse)
0
See CV #125 for details.
#125  Front headlight
#126  Rear headlight
#127
-
#132
Special effects for
FO1, FO2, FO3,
FO4, FO5, FO6
0
see CV #125 for details
#127  FA1 #128  FA2
#129  FA3 #130  FA4
#131  FA5 #132  FA6
#159,
#160
Special effects for
FO7, FO8
0
see CV #125 for details
#159  FA7 #160  FA8
#62
Effects modifications
0 - 9
0
Change of minimum dimming value
#63
Light effects modifica-
tion
or
Stop light OFF delay
0 - 99
0 - 255
51
Tens digit: sets cycle time (0 - 9, default 5), or start-
up time during “soft start” with 001101 (0 - 0,9s)
Ones digit: extends OFF time
For stop light OFF delay (001110xx in CV #125, 126
or 127): Time in tenths of a second the stop lights
remain ON after the street car comes to a full stop
(range: 0 – 25 sec.).
#64
Effects modifications
0 - 9
5
Ditch light off time modification
#64
Effects modifications
0 - 9
0
Bit 7 - 4: define a ditch light-key (function key+1)*16
consequent: 0=F2, 1=F0, 2=F1,.. 15=F14
Bit 3 - 0: Ditch light OFF time modification [s]
#393
ZIMO-Config. 5
0 – 255
0
Bit 0 = 1: activate ditch light if bell is played
Bit 1 = 1: activate ditch light if horn is played
1
Special tip for ditch lights: Those are only active if the headlights (F0) are turned on as well as function F2; this is equivalent to the American proto-
type. The “ditch lights” only function, if the Bits in CV # 33 and # 34 are configured (the definition in CV # 125 - 128 is not sufficient, but additionally re-
quired). Example: If ditch lights are defined for FA1 and FA2 , the Bits 2, 3 in CVs # 33, 34 must be on (e.g. CV # 33 = 00001101, CV # 34 =
00001110).
