Large-scale Decoder & Sound Decoder MX695, MX696, MX697, MX699 Page 57
#317
Playback length for
random generator Z1
0 - 255
=
0 - 255 sec
5
The sound sample assigned to the random generator Z1
(most often the compressor) is played back for the number of
times defined in CV #317.
= 0: Sample plays once (in the defined duration)
#318
#319
#320
As above but for
sound generator Z2
0 - 255
0 - 255
0 - 255
20
80
5
By default, Z2 is assigned for coal shoveling at stand-still.
#321
#320
#323
As above but for
sound generator Z3
0 - 255
0 - 255
0 - 255
30
90
3
By default, Z3 is assigned for the injector at stand-still.
#324
#325
#326
As above but for
sound generator Z4
0 - 255
0 - 255
0 - 255
As delivered, this random generator is not assigned to any
sound.
#327
#328
#329
As above but for
sound generator Z5
0 - 255
0 - 255
0 - 255
As delivered, this random generator is not assigned to any
sound.
#330
#331
#332
As above but for
sound generator Z6
0 - 255
0 - 255
0 - 255
As delivered, this random generator is not assigned to any
sound.
#333
#334
#335
As above but for
sound generator Z7
0 - 255
0 - 255
0 - 255
As delivered, this random generator is not assigned to any
sound.
#336
#337
#338
As above but for
sound generator Z8
0 - 255
0 - 255
0 - 255
As delivered, this random generator is not assigned to any
sound.
#341
Switch input 1
Playback duration
0 - 255
=
0 - 255 sec
0
The sound sample allocated to switch input 1 is played back
for the duration defined with this CV.
= 0: Play back once (duration as recorded)
#342
Switch input 2
Playback duration
0 - 255
=
0 - 255 sec
0
The sound sample allocated to switch input 2 is played back
for the duration defined with this CV.
= 0: Play back once (duration as recorded)
#343
Switch input 3
(if not used for the
cam sensor)
Playback time
0 - 255
=
0 - 255 sec
0
The sound sample allocated to switch input 3 is played back
for the duration defined with this CV.
= 0: Play back once (duration as recorded)
8 CV – Summery List
This list summarizes all CV's in numerical order, with very short descriptions (as a reminder).
Detailed information can be found in the preceding chapters ("Configure", "ZIMO Sound").
The “red” column: Denotes the subchapter in chapter 3 “Addressing, Programming” or another main chapter.
CV
Designation
Range
Default
Description
4
#1
Short address
1 – 127
3
The “short” address; active when Bit 5 in CV #29 is
0.
6
#2
Start voltage
1 - 255
1
Internal speed step for lowest external speed step.
7
#3
Acceleration rate
0 - 255
(2)
Multiplied by 0.9 equals’ acceleration time.
7
#4
Deceleration rate
0 - 255
(1)
Multiplied by 0.9 equals’ deceleration time.
6
#5
Top speed
0 - 255
1 (=255)
Internal speed step for highest external speed step.
6
#6
Medium speed
32 - 128
1 (=1/3 # 5)
Internal speed step for medium external speed
step.
3
#7
SW-Version number
Read-
only
-
The current SW number; for subversion see CV
#65.
3
#8
Manuf.-ID, Reset, Set
0, 8, Set
#
145 (ZIMO)
given by the NMRA; CV #8 = 8  Hard Reset.
6
#9
Motor regulation.
1 - 255
55
Sample time (tens digit), sample rate (ones digit)
