Page 58 Large-scale Decoder & Sound Decoder MX695/6/7/9
Internal speed step, where BEMF intensity per
CV#113.
Select analog functions F1 (Bit 0), F2 (Bit 1)...
Select analog functions, F0 forw (Bit 0), rev (Bit 1)...
The long address. Active when CV #29, Bit 5 = 1.
Consist address active when > 0.
Select consist functions F1 (Bit 0), F2 (Bit 1)….
Select consist function F0 forw (Bit 0), rev (Bit 1).
For temporary adjustment to CV #3
For temporary adjustment to CV #4
Bit 0 = 1: Stop, with right rail Bit 1: left rail
Bit 0 = 1: RailCom (Broadcast) Bit 1 = 1: Data
14 =
0000 1110
with Bits 1,
2, 3 (28 SS,
Analog,
RailCom)
Bit 0 – Direction: 0 = normal, 1 = reversed
Bit 1 – Speed step system: 0 = 14, 1 = 28, 128
Bit 2 – Automatic analog operation
Bit 3 – RailCom: 0 = OFF, 1 = ON
Bit 4 – Speed curve: 0 = 3-point, 1 = free definition
Bit 5 – Short/long address: 0 = CV #1, 1 = CV‘s
#17,18
Function mapping for F0 forward
Function mapping for F0 reverse
Function mapping for F1 ... F12
Multiplied by 0.4 = signal controlled acceleration
Multiplied by 0.4 = signal controlled deceleration
Speed step for each of the 5 HLU speed limits
PID regulation: P-Value (tens digit), I-Value (Ones
digit)
Value = 1/10 of fixed voltage. “0” = track voltage.
Load compensation at low speeds
Delay for HLU changes, in tenth of a second
Reduction of function output voltage through PWM.
Configurations not covered by NMRA mapping
Adjusts minimum dim value
Cycle time (tens digit), Off-time extension (ones dig-
it)
Ditch light off-time modification
Completes the version number in CV #7.
Multiplies speed step by trim value/128
Internal speed step for each of the 28 external steps
Multiplies speed step by trim value/128
Free memory space for user data
Light suppression for cab 1 (forward)
Light suppression for cab 2 (rear)
Special ZIMO
configuration bits
4 =
00000100
also Bit 2 = 1
(Loco ID puls-
es ON,
20 kHz)
Bit 1 = 1: High frequency acknowledgements
Bit 2 = 0 / 1: ZIMO loco ID ON/OFF
Bit 3 = 1: 8 Functions-Mode (for old ZIMO systems)
Bit 4 = 1: Pulse chain recognition (for old LGB-
System)
Bit 5 = 0 / 1: Motor control at 20 kHz or 40 kHz
Bit 6 = 1: „Märklin“-Braking (+ CV # 29, Bit 2, # 124,
5)
Intensity reduced at speed step defined in CV #10.
Individual outputs exempted from dimming per CV
#60
Eff 48: Pull-in V. (tens digit), Hold voltage (ones digit)
Unload (Hundredth) Separat.(Tens), speed (Ones
digit)
ON time (Tens digit), OFF time (Ones digit)
Function outputs included for flashing as per CV
#117.
Enter FO for low-beam switching with F6 as per CV
#60
Enter FO for low-beam switching with F7 as per CV
