Page 48 Large-scale Decoder & Sound Decoder MX695/6/7/9
CV
Bezeichnung
Werte-
Bereich
Default
Beschreibung
situation. Define the (sound) speed in CV #375 (often used
for idle sound while coasting).
= 0: does NOT mean F0, but rather that NO key is assigned
for coasting.
= 1 ... 28: One of the function keys F1 … F28 for “Coasting“
# 375
Coasting-Step
(or Notching)
0 - 10
0
Motor speed (sound) to be activated with coasting key (as
per CV #374), independent of driving situation.
= 0: Idle sound (typical coasting situations)
= 1 … 10: Sound speed (Diesel engines typically have 5 to
10 notches, which can be activated with the coasting key.
The volume for “background” sounds (boiling, brake squealing etc.), function sounds, random
sounds and switch input sounds can be set within the sound selection proccedures (see the
“CV #300 procedures” above).
More convenient however is the direct volume adjustment by CV’s (especially when no
sound selection is necessary, which is often the case). Of course, not all sounds listed below
are part of every sound project. Changing sound CV values of sound files that are not part of
the relevant sound project have no effect.
Background sounds - Volume adjustments:
#574
Boiling
0 - 255
0
Boiling volume
#576
Directions change
0 - 255
0
Directions change volume
#578
Brake squeal
0 - 255
0
Brake squeal volume
#580
Thyristor sound
0 - 255
0
Thyristor sound volume (ELECTRIC engine)
#582
Start whistle/horn
0 - 255
0
Start whistle/horn volume
#584
Blow-off
0 - 255
0
Blow-off volume (STEAM engine)
#586
Electric motor
0 - 255
0
Electric motor volume (ELECTRIC engine)
#588
Driving sounds
0 - 255
0
Driving sounds volume
#590
Switch gear
0 - 255
0
Switch gear volume (ELECTRIC engine)
#592
Second Thyristor
0 - 255
0
Second Thyristor volume (ELECTRIC engine)
#594
Panto up
0 – 255
0
Pantograph up volume (ELECTRIC engine)
#596
Panto down
0 – 255
0
Pantograph down volume (ELECTRIC engine)
#598
Panto stop (down)
0 – 255
0
Pantograph stop (down) (ELECTRIC engine)
#600
Turbo
0 - 255
0
Turbocharger volume (DIESEL engine)
#602
Dynamic brakes
0 - 255
0
Dynamic brake volume (ELECTRIC engine)
Note: The CV ahead of the CV’s listed (#573, 575 etc.) contain the sound sample numbers to be played.
Function sounds - Volume adjustments:
CV
Designation
Range
De-
fault
Description
#571
Function sound F0
0 - 255
=
100, 1-100 %
0
Sound volume operated with function key F0
= 0: full volume, original sound sample volume (same as 255)
= 1 .. 254: reduced volume 1 - 99,5 %
= 255: full volume
#514
Function sound F1
0 - 255
0
Volume for function sound F1
#517
Function sound F2
0 - 255
0
Volume for function sound F2
#520
Function sound F3
0 - 255
0
Volume for function sound F3
#523
Function sound F4
0 - 255
0
Volume for function sound F4
#526
Function sound F5
0 - 255
0
Volume for function sound F5
#529
Function sound F6
0 - 255
0
Volume for function sound F6
#532
Function sound F7
0 - 255
0
Volume for function sound F7
#535
Function sound F8
0 - 255
0
Volume for function sound F8
#538
Function sound F9
0 - 255
0
Volume for function sound F9
#541
Function sound F10
0 - 255
0
Volume for function sound F10
#544
Function sound F11
0 - 255
0
Volume for function sound F11
#547
Function sound F12
0 - 255
0
Volume for function sound F12
#550
Function sound F13
0 - 255
0
Volume for function sound F13
#553
Function sound F14
0 - 255
0
Volume for function sound F14
#556
Function sound F15
0 - 255
0
Volume for function sound F15
#559
Funktions-Sound F16
0 - 255
0
Volume for function sound F16
#562
Function sound F17
0 - 255
0
Volume for function sound F17
#565
Function sound F18
0 - 255
0
Volume for function sound F18
#568
Function sound F19
0 - 255
0
Volume for function sound F19
#674, #677…#698 = volume for sounds on F20, F21…F28.
Note: The in-between CV’s above (#570, 572, #513, 515, 516, 518 etc.) hold information for the relevant
sound samples (sample numbers, loop parameters etc.), which can also be modified if needed, usually with
the CV #300 procedures.
Switch input sounds - Volume adjustments:
#739
Switch input sound S1
0 - 255
=
100, 1-100 %
0
Volume setting for the sound activated by switch input S1.
= 0: full volume, original sample volume (same as 255)
= 1 .. 254: reduced volume 1 - 99,5 %
= 255: full volume
#741
Switch input sound S2
0 - 255
0
Volume setting for the sound activated with switch input S2
#743
Switch input sound S3
0 - 255
0
Volume setting for the sound activated with switch input S3
NOTE: If a decoder comes with a potentiometer for volume control (mostly on large-scale
decoders), the pot meter should NOT be fully opened if full volume is not really desired (Loss of
sound quality if pot meter is fully open and at the same time the volume is heavily reduced by
CV’s!).
