Page 2 of 12 Zip FlushMaster Pearl Installation & Maintenance Instructions - 82902 - January 2012 v1.00
You may need these accessories ( see page 3 for package contents).
Table of Contents
Key Features ................................................. 3
Read These Warnings First ............................ 3
Check Your Package ...................................... 3
Installation Procedure .................................... 3
Set Up Water Discharge ................................ 4
Install Sensor ................................................. 6
Connect Latching Valve Cable ........................ 7
Connect Optional Power Pack ........................ 8
Set Flush Timing ............................................ 8
Completing Installation .................................. 9
Maintenance Instructions ............................... 10
Problem Solving............................................. 11
Contact Details .............................................. 12
99168 Pearl Water Saver Sensor only (64mm body)
99021 Zip FlushMaster Cistern Autosyphon 1.00 inch BSP/ 25 mm
99022 Zip FlushMaster Cistern Autosyphon 1.25 inch BSP/ 32 mm
99023 Zip FlushMaster Cistern Autosyphon 1.50 inch BSP/ 38 mm
99024 Zip FlushMaster Direct Injection Airbreak 1.00 inch BSP / 25 mm
99025 Zip FlushMaster Direct Injection Airbreak 1.25 inch BSP/ 32 mm
99026 Zip FlushMaster Direct Injection Airbreak 1.50 inch BSP/ 38 mm
Fixing
bracket
99031 Zip FlushMaster AC Power Pack
Accessories
99039 -Restrictaflow
41092 Mk 2 Retrofit Sensor DC (105mm body) WS006 ( Valve assy not included )
41093 Mk 2 Retrofit Sensor AC (105mm body) WS007 ( Valve assy not included )
