Quick Start Installation Guide
807118UK v1.12 12.23 G5 BC Quick Start Guide
SECTION 8: Set the bypass & install the limescale filter
For Limescale filter installation instructions, scan the QR code on
the Limescale filter carton.
Available as optional accessory - UK only.
Set the HydroTap Command Centre bypass valve
(Rear of the Command Centre)
Place the filter in position vertically on a stable surface
sufficiently robust to support its weight.
Ensure that the fibre washers supplied are fitted in the threaded
hose ends & flush the filter before use.
IN
OUT
• If space is available, fit the filter in the
Command Centre cupboard.
• If space is limited, cut a hole through &
fit the filter in an adjacent cupboard.
Install the Limescale filter
