Quick Start Installation Guide
807118UK v1.12 12.23 G5 BC Quick Start Guide
15
SECTION 7: Connect the water supply
15mm
mains water
connection
(not supplied)
Install rail
(supplied)
Install vertically,
flow downwards
Male - Female
adaptor
(supplied)
Strainer
(supplied)
Braided hose to
Command Centre
(supplied)
Connect together
Connect to
Command Centre
see pages 20-23
Connected
together
Before
connection
Note Mixer tap installations also use a ‘Tee piece’ as part of the water supply
plumbing connections, see the Tap installation instructions supplied with the
Mixer Tap to connect the water supply if using the mixer tap option.
Valves and fittings must be sealed
with PTFE tape if compression
seals are not included.
UK connections
Use instructions
supplied with Install rail.
To Next Page
