14
Installation instructions & user manual
9120-25693 v3.00 Oct 2018 - ZIP CEX
Technical support
Tel: 0345 6 005 005 email: service@zipindustries.co.uk www.zipwater.co.uk
COMMISSIONING
Reinstallation
Shower application
Fig. 9
of these instructions.
Select the maximum allowable power rating depending on the local situation via the
up
and down arrow keys: 8.8 kW (display “88”) or 6.6 kW (display: “66“) 230 V.
Press key
to confirm the setting. The appliance starts operating.
Mark the set power rating on the rating plate.
Open the hot water tap. Check the function of the appliance.
After having set the maximum allowable power rating, the heating element will be
activated after approx. 10 - 30 seconds of water flow.
Explain operation of the appliance to the end user and leave the operating
instructions for their reference.
Complete the product registration card and return it to Zip or register the product on
line at www.zipwater.co.uk/product-registration.
The water heater’s temperature must be limited to
55 °C, if it is connected to a shower. The service
menu parameter “Temperature Limit“ (“tL”) must be
set to a value less or equal 55 °C (in consultation
with the customer) and the lock level must be
activated.
When the device is operated with preheated water,
it must be ensured that this temperature is limited to
55 °C as well.
If the appliance is to be recommissioned
under different installation conditions it may be
necessary to alter the maximum power rating.
This should only be done by a competent installer.
To re-set the maximum power rating use a
screwdriver (compliant to EN 60900, current
issue) to short circuit the two pins as shown in
Fig. 9.
This will reset all heater parameters to factory
settings.
Value “88” will flash in the display panel until the
maximum power rating has been selected.
