2. Technical Data
The power supply line from the distribution box to the charging point must
comply with electrical safety standards, according to the regulations of each
country.
Remember that the equipment is Cat II (Overvoltage Category). Depending on
the location, it may be necessary to install an external overvoltage protection to
the device.
AC Power Supply 230 V 50 Hz (±10%)
Single-Phase or Three-Phase.
Overvoltage Category Cat III.
Output Maximum Power
Three-Phase 22 kW
Single-Phase 7.4 kW
Consumption on standby
Three-Phase <1.5 W / per phase (@230V)
Single-Phase <1.5 W (@230V)
Maximum Output Current 32 A per phase / plug.
Insulation Class Class 1.
Charging System Mode 3.
Connection to Power Supply Permanent.
Protection Level IP 54 / IK 08
Installation Mode Wall-mounted
3 fixing points
HMI Display 22 x 70 mm
4 push-bottoms.
2 Status LEDs.
1 Energy Pulses LED.
