4. Physical Architecture and Mounting
4.1 Description
The mechanics of the device are based on the following parts:
- Base. Part that is attached to the wall.
- Front. Hides the active parts of the equipment and is attached to the base.
- Wire cover. Provides access to the electrical connection, communications and
configuration parts. In this way, there is no access to the internal parts either in the
installation or in the configuration of the equipment. This cover can be sealed with two
screws.
- Embellishment. Most visible part of the equipment, it offers the finishing line.
Figure 1. 5EVM's Mechanical Architecture.
